Heavy Duty Steel Bar Grating with Slip-Resistant Surface and Customizable Sizes for Catwalk Deck and Drain Trench Cover
Heavy Duty Steel Bar Grating with Slip-Resistant Surface and Customizable Sizes for Catwalk Deck and Drain Trench Cover
Heavy Duty Steel Bar Grating with Slip-Resistant Surface and Customizable Sizes for Catwalk Deck and Drain Trench Cover
Heavy Duty Steel Bar Grating with Slip-Resistant Surface and Customizable Sizes for Catwalk Deck and Drain Trench Cover
Heavy Duty Steel Bar Grating with Slip-Resistant Surface and Customizable Sizes for Catwalk Deck and Drain Trench Cover
Heavy Duty Steel Bar Grating with Slip-Resistant Surface and Customizable Sizes for Catwalk Deck and Drain Trench Cover
Specifications
Brand Name :
Gnee
MOQ :
2PCS
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
Shipped in 20 days after payment
Packaging Details :
Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Description

Steel bar grating with high strength and firm structure is made up of carbon steel, aluminum steel, or stainless steel. According to the manufacturing methods, it can be divided into four types: welded, press-locked, swage-locked, and riveted gratings. According to the surface shapes, it can be divided into smooth and serrated gratings. With various styles and sizes for choice, steel gratings are widely used in everyday life, such as stair treads, walkways, platforms, floors, various covers, wheeled equipment, security screens, heavy-duty constructions, and so on.


Product Features
Durability: Constructed from high-quality carbon or stainless steel, ensuring long-lasting performance in demanding environments.
Load-Bearing Capacity: Engineered to support heavy loads, making it ideal for industrial applications such as factories and warehouses.
Slip-Resistant Surface: Features a textured surface that enhances safety by reducing the risk of slips and falls.
Customizable Sizes: Available in various sizes and spacing options to meet specific project requirements and applications.


Material 1.Carbon Steel Q235 2.Stainless Steel 304 / 316
Type Press lokced / Flat bar / Serrated bar / I Bar
Bearing Bar Size 20 x 3 to 100 x 9;the specification of "I-section" is 25 x 5 x 3, 32 x 5 x 3, 38 x 5 x 3, 40 x 5 x 3, 50 x 5 x 3, 50 x 7 x 4, 55 x 7 x 4, 60 x 7 x 4, 65 x 7 x 4, 70 x 7 x 4, 75 x 7 x 4, etc
Bearing Bar Pitch 12.5 to 100 mm etc, 30, 40, 60mm are recommended, America standard is available
Cross Bar Pitch from18.5 to 101.6mm etc, 50, 100mm are recommended, America standard is available
Specification Size of bearing flat steel: 25x3mm / the center space: 30mm, 40mm, 50mm, 100mm
Size of horizontal pole: 10x2mm / the center space : 50mm, 100mm
Surface Treatment Untreated / Painting / Hot Dip Galvanizing
Steel Standard China GB700-88 / America ASTM (A36) / Britain ASTM (A36)
HDG Standard China GB/T13912-92 / America ASTM (A123) / Britain BS729
Quality Standard China YB/T4001-1998 America ANSI/NAAMM (MBG531-88)
Britain BS4592-1987 Australia AS1657-1992
