Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Specifications
Brand Name :
Gnee
MOQ :
2PCS
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
Shipped in 20 days after payment
Packaging Details :
Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Description
Hot DIP Galvanized Steel Driveway Grating
Steel grating is a widely used grid product with exceptional resistance to surface impact, making it ideal for various industrial applications including driveways, platforms, and walkways.
Product Classification
By Surface Shape:
  • Tooth-shaped steel grating
  • Pressure welded steel grating
  • L-type steel grating
  • Composite steel grating
By Surface Treatment:
  • Hot-dip galvanized steel grating
  • Spray paint steel grating
  • Stainless steel grating
Technical Specifications
Specification Details
Bearing Bar 25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10-100x10mm, etc.

I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3, etc.

US Standard: 1"x3/16", 1 1/4"x3/16", 1 1/2"x3/16", 1"x1/4", 1 1/4"x1/4", 1 1/2"x1/4", 1"x1/8", 1 1/4"x1/8", 1 1/2"x1/8", etc.
Bearing Bar Pitch 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm, etc.

US Standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2, etc.
Twisted Cross Bar Pitch 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2" & 4", etc.
Material Grade ASTM A36, A1011, A569, Q235, S275JR, SS304, SS400, Mild steel & Low carbon steel, etc.
Surface Treatment Black, self color, hot dip galvanized, painted, spray coating
Grating Style Plain / Smooth, Serrated / teeth, I bar, serrated I bar
Standard China: YB/T 4001.1-2007
USA: ANSI/NAAMM(MBG531-88)
UK: BS4592-1987
Australia: AS1657-1985
Germany: DIN24537-1-2006
Japan: J Standards
Product Images
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
Hot DIP Galvanized Steel Grating with Strong Resistance to Surface Impact for Various Industrial Applications
