Hot DIP Galvanized Finish Plain Steel Bar Grating with Customizable Dimensions for Industrial Flooring
Hot DIP Galvanized Finish Plain Steel Bar Grating with Customizable Dimensions for Industrial Flooring
Hot DIP Galvanized Finish Plain Steel Bar Grating with Customizable Dimensions for Industrial Flooring
Hot DIP Galvanized Finish Plain Steel Bar Grating with Customizable Dimensions for Industrial Flooring
Hot DIP Galvanized Finish Plain Steel Bar Grating with Customizable Dimensions for Industrial Flooring
Hot DIP Galvanized Finish Plain Steel Bar Grating with Customizable Dimensions for Industrial Flooring
Hot DIP Galvanized Finish Plain Steel Bar Grating with Customizable Dimensions for Industrial Flooring
Hot DIP Galvanized Finish Plain Steel Bar Grating with Customizable Dimensions for Industrial Flooring
Hot DIP Galvanized Finish Plain Steel Bar Grating with Customizable Dimensions for Industrial Flooring
Hot DIP Galvanized Finish Plain Steel Bar Grating with Customizable Dimensions for Industrial Flooring
Specifications
Brand Name :
Gnee
MOQ :
2PCS
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
Shipped in 20 days after payment
Packaging Details :
Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Description
Steel grating, also known as steel grid or bar grating, is a versatile and robust flooring solution designed for industrial, commercial, and architectural applications. Made from high-quality carbon or stainless steel, our steel grating features a lightweight yet durable design that ensures excellent load-bearing capacity and long-lasting performance.


Various customizations are accepted

1.Bearing bar depth
2.Bearing bar thickness
3.Bearing bar pitch
4.Cross bar pitch
5.Span and Width (mesh size)

Daily application
flooring, catwalk, decking, stair tread, fencing, ramp, dock, trench cover, drainage pit cover, maintenance platform, workshops, motor rooms, trolley channels, heavy loading areas, boiler equipment and heavy equipment areas, etc.

No. Item Detailed Description
1 Bearing Bar 25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10---100x10mm etc; I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc
US standard: 1' ' x3/16' ' , 1 1/4' ' x3/16' ' , 1 1/2' ' x3/16' ' , 1' ' x1/4' ' , 1 1/4' ' x1/4' ' , 1 1/2' ' x1/4' ' , 1' ' x1/8' ' , 1 1/4' ' x1/8' ' , 1 1/2' ' x1/8' ' etc
2 Bearing Bar Pitch 12.5, 15, 20, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc
3 Twisted Cross Bar Pitch 38.1, 40 50, 60, 76, 80, 100, 101.6, 120mm, 2' ' & 4' ' etc
4 Steel Grade ASTM A36, A1011, A569, Q235, S235JR, S275JR, SS304, Mild steel & Low carbon steel, etc
5 Surface Treatment Black, self colour, hot dip galvanized, painted, spray coating
6 Grating Style Plain / Smooth, Serrated /teeth, I bar, serrated I bar
7 Grating Standard China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88),
UK: BS4592-1987, Australia: AS1657-1985, Japan: JIS
