High-Transparency Double-Sided TPU-Coated PET Film HT-15 Series
High-Transparency Double-Sided TPU-Coated PET Film HT-15 Series
High-Transparency Double-Sided TPU-Coated PET Film HT-15 Series
High-Transparency Double-Sided TPU-Coated PET Film HT-15 Series
High-Transparency Double-Sided TPU-Coated PET Film HT-15 Series
High-Transparency Double-Sided TPU-Coated PET Film HT-15 Series
Specifications
Chemicalresistance :
Good resistance to oils, greases, and many solvents
Certification :
ISO 13485, ISO 9001, IATF 16949, FCC, SGS
Transparency :
Above 90%
Model Number :
HT15
Surface Quality :
Low Haze&Smooth Finish
Ink Compatibility :
UV & Solvent Ink
Price :
USD 0.166~1.316
Tensile strength :
MD 163 MPa / TD 180 MPa
Printed :
UV & Solvent Ink Compatibility
Supply Ability :
500000 square meter
Film Type :
BOPET Base Film
Roll Length :
500m-1000m
MOQ :
1 square meter
Delivery Time :
7 working days
Light Transmittance :
>90%
Optical Properties :
Low haze
Payment Terms :
T/T,Western Union
Type :
Clear PET Roll
Place of Origin :
Shenzhen, China
Width :
Customizable (e.g., 500mm, 1000mm)
Brand Name :
XH
Surfacefinish :
Glossy or Matte
Packaging Details :
Tray / Carton
Description
High-Transparency Double-Sided TPU-Coated PET Film HT-15 Series
Engineered for Precision Die-Cutting and High-Quality Screen Printing
Get It Right the First Time, Eliminate Rework
Solving Two Core Pain Points in Panel Processing
In membrane switch and nameplate production, nothing is more frustrating than:
  • Die-cut edges that turn white or delaminate, leading to high scrap rates
  • Poor ink adhesion that fails cross-hatch tests, causing customer rejections
The HT-15 series high-transparency PET film was developed specifically to address these two challenges. With our double-sided TPU coating technology, we preserve the excellent stiffness and dimensional stability of PET while imparting superior die-cutting toughness and strong ink anchorage. The result: smoother production and more reliable finished products.
Why HT-15 is the Ideal Choice for Panel Die-Cutting and Screen Printing Houses
Your Production Challenge How HT-15 Solves It Value Delivered
Die-cut edges whiten or delaminate Double-sided TPU coating enhances interlayer adhesion, delivering smooth, white-free, and delamination-free cut edges Reduced scrap, extended die life, lower overall cost
Poor ink adhesion, cross-hatch test fails Specialty coating ensures 100/100 pass for both UV and conventional inks per JIS K5600 Dramatically improved printing yield; easily passes end-customer reliability tests
Rainbow patterns or haze on high-clarity panels 92% light transmittance and <1.3% haze deliver superior optics with minimal rainbow effects Crystal-clear displays enhance product aesthetics, meeting premium appliance and automotive requirements
Dimensional shifts during multi-color registration Heat shrinkage is just 1.0% in MD and 0.0% in TD - outstanding dimensional stability Ensures accurate multi-color registration; large panels stay true to size
Deformation or cracking under harsh conditions High tensile strength (MD 163 Mpa) and excellent elongation (MD 154%) provide rugged durability Produces durable membrane switches and panels ready for industrial and automotive applications
Key Product Specifications
Property Unit Typical Value Test Method
Thickness μm 100 / 125 / 188 / 250 ASTM D374
Light Transmittance % ≥92 JIS K7136
Haze % <1.3 JIS K7136
Cross-Hatch Test - 100/100 Pass JIS K5600
Heat Shrinkage (MD/TD) % 1.0 / 0.0 JIS C2318
Tensile Strength (MD/TD) Mpa 163 / 180 ASTM D882
Elongation at Break (MD/TD) % 154 / 110 ASTM D882
Available in 100/125/188/250 μm thicknesses, roll width 1020mm, length 200m - meeting diverse panel processing requirements.
Broad Applications to Help You Expand Your Business
The HT-15 series is engineered for premium human-machine interfaces and decorative panels, ideal for:
  • Membrane switch panels
  • Home appliance control panels and nameplates
  • Remote control and keypad panels
  • Instrumentation and equipment nameplates
  • Automotive interior touch panels
Why Partner with HT-15?
  • Consistent Parameters, Batch-to-Batch Stability: Strict quality control ensures every batch delivers consistent properties, minimizing your machine setup time.
  • Free Samples for In-House Validation: We provide complimentary samples so you can test on your own production line - let the results speak for themselves.
  • Professional Technical Support: Our technical team is available to provide coating matching and process recommendations tailored to your specific application.
Request Your Free Sample Today
Don't let material issues compromise your yield or delay your deliveries.
Click the button below to request a free sample of the HT-15 series and see its outstanding performance on your production line firsthand.
