15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
15 Ton 16 Ton Heavy Duty Construction Hydraulic Straight Arm Boom Truck Crane
Specifications
Hydraulic Pump Brand :
Top Brand
Max. Speed :
90km/h
Machinery Test Report :
Provided
Application :
Construction/Warehouse/Terminals/Logistics/Rescue
Hydraulic Cylinder Brand :
Top Brand
Warranty :
1 Year
Driving Style :
6x4, Left/Right hand drive
Core Components :
Pressure Vessel, Motor, Bearing, Gear, Pump, Gearbox, Engine
Emission Standard :
EURO 2
Color :
Blue, Green, Yellow, White
Fuel Tank :
270L
Place of Origin :
SHAANXI,XIAN
Brand Name :
SHACMAN
MOQ :
1
Price :
Negotiable
Max. Operating Pressure :
28Mpa
Make :
XCMG/SANY/SUNHUNK
Max. Lifting Height :
23.1m
Cargo Size :
9000x2450x800mm
Video outgoing-inspection :
Provided
UNIQUE SELLING POINT :
High operating efficiency/Fully hydraulic system
Oil Flow Volume :
80+50L/min
Span :
2.44~8.4m
Engine Brand :
Weichai
Engine :
WEICHAI, WP10.340E22
Delivery Time :
35-55days
Weight (KG) :
6880 kg
Rated Lifting Moment :
430kN.m
Hydraulic Valve Brand :
Top Brand
Wheelbase :
5775+1400mm
Vehicle Speed Ratio :
16T HD dual-stage 4.769
Description
Truck Brand
SHACMAN F3000 Series Truck-mounted Crane
Drive Style
Left or right hand drive
Chassis
Drive Type
4x2
6x4
8x4
Engine
WP10.300E22
WP10.340E22
WP10.380E22
Power
300hp
340hp
380hp
Emission Standard
EURO Ⅱ
EURO Ⅱ
EURO Ⅱ
Frame
870x300(8+5)mm
870x300(8+5+8)mm
870x300(8+5+8)mm
Wheelbase
5600mm
5775+1400mm
2100+4575+1400mm
Vehicle Speed Ratio
16T HD dual-stage 4.769
16T HD dual-stage 4.769
16T HD dual-stage 5.262
Crane
Max. Lifting Weight
5000/6300/7000kg
10000/12000kg
16000/18000/20000kg
Max. Lifting Torque
125/157.5/175kN·m
260/300kN·m
430/470/520kN·m
Max. Working Radius
11.2-13.5m
14.5-21.77m
21.77-23.7m
Max. Lifting Height
12.7-15.3m
16.3-23.1m
24.1-26.4m
Luffing Range
0°～75°
0°～75°
0°～75°
Slewing Angle
360° full turn
360° full turn
360° full turn
Max. Operating Pressure
22/23MPa
26/28Mpa
28Mpa
Oil Flow Volume
63L/min
63+50L/min
80+50L/min
Crane Weight
2200/2330/2420kg
3693/4300kg
6880/6970/7600kg
