SHACMAN F3000 6x4 20000L Fuel Transport Tanker Truck Weichai 340HP Diesel 6 Compartment Euro 2
SHACMAN F3000 6x4 20000L Fuel Transport Tanker Truck Weichai 340HP Diesel 6 Compartment Euro 2
SHACMAN F3000 6x4 20000L Fuel Transport Tanker Truck Weichai 340HP Diesel 6 Compartment Euro 2
SHACMAN F3000 6x4 20000L Fuel Transport Tanker Truck Weichai 340HP Diesel 6 Compartment Euro 2
SHACMAN F3000 6x4 20000L Fuel Transport Tanker Truck Weichai 340HP Diesel 6 Compartment Euro 2
SHACMAN F3000 6x4 20000L Fuel Transport Tanker Truck Weichai 340HP Diesel 6 Compartment Euro 2
SHACMAN F3000 6x4 20000L Fuel Transport Tanker Truck Weichai 340HP Diesel 6 Compartment Euro 2
SHACMAN F3000 6x4 20000L Fuel Transport Tanker Truck Weichai 340HP Diesel 6 Compartment Euro 2
SHACMAN F3000 6x4 20000L Fuel Transport Tanker Truck Weichai 340HP Diesel 6 Compartment Euro 2
SHACMAN F3000 6x4 20000L Fuel Transport Tanker Truck Weichai 340HP Diesel 6 Compartment Euro 2
Specifications
Chassis Brand :
SHACMAN F3000 6x4
Tank Material :
6mm Carbon Steel with Anti-corrosion Coating
Meter :
Digital flow meter with ticket printer
Brand Name :
SHACMAN
Tank Capacity :
20,000 Liters
Transmission :
FAST 9-speed Manual
Emission Standard :
Euro 2 / Euro 3
Discharge System :
Bottom loading with API couplers
Driving Type :
LHD / RHD Available
MOQ :
1 Unit
Engine Power :
340 HP
Model Number :
F3000 6x4 20KL-FT
Vapor Recovery :
Stage I and II vapor recovery system
Payment Terms :
T/T,L/C
Supply Ability :
30 Units per Month
Engine Model :
Weichai WP10.340E32
Packaging Details :
Nude packing with anti-rust coating; optional shrink-wrap for ocean freight
Place of Origin :
Shaanxi, China
Certification :
ISO 9001:2015, CCC
Price :
Negotiable
Compartments :
6 independent chambers
Pump Type :
Gear pump, 60 m3/h flow rate
Delivery Time :
35-55 working days after deposit
Description

SHACMAN F3000 6x4 20,000L Multi-Compartment Fuel Transport Tanker Truck

6-compartment fuel delivery truck — bottom loading, vapor recovery, digital metering

F3000 6x4 fuel tanker — 6-compartment tank for multi-grade delivery

Bottom loading cabinet with API couplers and pneumatic controls

This 20,000-liter fuel tanker is built for petrol station supply and bulk fuel distribution. The SHACMAN F3000 6x4 chassis gives you the payload capacity and off-road capability when delivery points are at construction sites or remote depots. The tank is 6mm carbon steel, internally coated for diesel and gasoline compatibility, with six independent compartments so you can carry different fuel grades in a single trip.

The plumbing setup includes a bottom loading system with API standard couplers, so depot loading is fast and spill-free. Each compartment has its own pneumatic bottom valve controlled from the curbside cabinet. Discharge side is equipped with a gear pump running off the PTO delivering about 60 cubic meters per hour — you will offload a full compartment in under 10 minutes. A digital flow meter with ticket printer is standard, which your customers will appreciate for accurate billing.

Key Specifications

Tank Capacity20,000 Liters
Compartments6 independent chambers
Tank Material6mm Carbon Steel + Internal Coating
LoadingBottom loading, API couplers
Discharge PumpGear pump, 60 m3/h
MeteringDigital flow meter with ticket printer

Curbside discharge with digital metering and vapor recovery

Safety kit is comprehensive: emergency shut-off valves at each compartment, a vapor recovery system for both Stage I (loading) and Stage II (unloading), static grounding reel, two 6kg dry powder fire extinguishers, and full-length side under-run protection. The tank passed hydrostatic pressure testing at 0.036 MPa. If you need it configured for aviation fuel (Jet A-1), we can swap seals and fittings to meet JIG standards. Let us know your specific delivery profile and we will spec it right.
