H3C S9850-32H Data Center Switch with 32 × 100G QSFP28 Ports, 6.4 Tbps Switching Capacity, and 2024 Mpps Forwarding Capacity
H3C S9850-32H Data Center Switch with 32 × 100G QSFP28 Ports, 6.4 Tbps Switching Capacity, and 2024 Mpps Forwarding Capacity
H3C S9850-32H Data Center Switch with 32 × 100G QSFP28 Ports, 6.4 Tbps Switching Capacity, and 2024 Mpps Forwarding Capacity
H3C S9850-32H Data Center Switch with 32 × 100G QSFP28 Ports, 6.4 Tbps Switching Capacity, and 2024 Mpps Forwarding Capacity
H3C S9850-32H Data Center Switch with 32 × 100G QSFP28 Ports, 6.4 Tbps Switching Capacity, and 2024 Mpps Forwarding Capacity
H3C S9850-32H Data Center Switch with 32 × 100G QSFP28 Ports, 6.4 Tbps Switching Capacity, and 2024 Mpps Forwarding Capacity
H3C S9850-32H Data Center Switch with 32 × 100G QSFP28 Ports, 6.4 Tbps Switching Capacity, and 2024 Mpps Forwarding Capacity
H3C S9850-32H Data Center Switch with 32 × 100G QSFP28 Ports, 6.4 Tbps Switching Capacity, and 2024 Mpps Forwarding Capacity
Specifications
Chassis :
LS-9850-32H-H1
Model Number :
S9850-32H
Item :
S9850-32H
Brand Name :
H3C
Forwarding capacity :
2024 Mpps
Delivery Time :
2-3 work days
Switching :
6.4 Tbps
Supply Ability :
50pcs per week
Power module slot :
2
Out-of-band management port :
One GE copper port and one GE fiber port
Payment Terms :
T/T
Weight(Full loaded) :
≤ 15 kg (33.07 lb)
Place of Origin :
China
Serial console port :
1
MOQ :
1/set
Description

H3C S9850 high-density intelligent series switches is developed for data centers and cloud computing networks. It provides powerful hardware forwarding capacity and abundant data center features. It provides up to 32*100G ports and 2 out-of-band management ports (one fiber port and one copper port). The 100G ports are 100G/40G autosensing and each can be split into four interfaces. This enables the switch to provide up to 128*25G or 10G ports. The switch supports modular power supplies and fan trays. By using different fan trays, the switch can provide field-changeable airflows.

The switch is an ideal product for high-density 100GE or 25GE accessing and aggregation at data centers and cloud computing networks. It can also operate as a TOR access switch on an overlay or integrated network.

S9850-32H

The switch provides 32 × 100G QSFP28 ports, 2 × 1G SFP ports, 5 × fan tray slots, 2 × out-of-band management ports, 1 × mini USB console port, and 1 × USB port. The switch uses 650W AC or DC removable power modules and supports 1+1 power module redundancy.

Item S9850-32H
Chassis LS-9850-32H-H1
Dimensions (H × W × D) 43.6 × 440 × 460 mm (1.72 × 17.32 × 18.11 in)
Weight(Full loaded) ≤ 15 kg (33.07 lb)
Serial console port 1
Out-of-band management port One GE copper port and one GE fiber port
Mini USB console port 1
USB port 1
QSFP28/QSFP+ 32
SFP port 2
CPU LS-9850-32H-A: 4 cores, 2.4 GHz
LS-9850-32H-H1: 4 cores, 2.2 GHz
Flash/SDRAM LS-9850-32H-A: 4GB/8GB
LS-9850-32H-H1: 8GB/8GB
Latency < 1μs (64-byte )
Switching capacity 6.4 Tbps
Forwarding capacity 2024 Mpps
Buffer 32M
AC-input voltage 90v to 264v
DC-input voltage –40v to –72v
Power module slot 2
Fan tray slot 5
Air flow direction From front to rear or from rear to front
