Amphenol T8200 E D GN 5P R Wall Mount CO2 Humidity and Temperature Transmitter for HVAC Applications
Amphenol T8200 E D GN 5P R Wall Mount CO2 Humidity and Temperature Transmitter for HVAC Applications
Amphenol T8200 E D GN 5P R Wall Mount CO2 Humidity and Temperature Transmitter for HVAC Applications
Amphenol T8200 E D GN 5P R Wall Mount CO2 Humidity and Temperature Transmitter for HVAC Applications
Amphenol T8200 E D GN 5P R Wall Mount CO2 Humidity and Temperature Transmitter for HVAC Applications
Amphenol T8200 E D GN 5P R Wall Mount CO2 Humidity and Temperature Transmitter for HVAC Applications
Specifications
Description :
Multifunction RoHS
Mfr. Part # :
T8200-E-D-GN-5P-R
Model Number :
T8200-E-D-GN-5P-R
Description

Product Overview

The Telaire 8000 Ventostat series offers wall-mount CO2, humidity, and temperature transmitters designed for controlled ventilation in commercial HVAC applications. These transmitters help maintain indoor air quality, prevent energy losses from over-ventilation, and support demand-controlled ventilation strategies, particularly in buildings with fluctuating occupancy. Featuring patented sensing technologies like ABC Logic for self-calibration and a lifetime CO2 calibration guarantee on select models, these units ensure accuracy and minimize maintenance. Their two-piece design facilitates easy installation and replacement without rewiring, making them ideal for controlling specific areas such as conference rooms, classrooms, and meeting halls.

Product Attributes

  • Brand: Telaire (Amphenol Advanced Sensors)
  • Series: Ventostat 8000
  • Sensing Technology: Patented Absorption Infrared Gas sensing engine
  • Calibration System: Patented ABC Logic self-calibration (T8100, T8300)
  • Calibration Guarantee: Lifetime for T8100/T8300 with ABC Logic; 24 months on mechanical defects
  • Enclosure Design: Modern, two-piece design for easy replacement
  • Certifications: CE and RoHS compliant
  • Optional Features: Customized branding, display, humidity sensing, BACnet output, pitot tube kit, splash-resistant enclosure, outside air enclosure, aspiration box for duct mounting.
  • Color Options: Black (B), White (W)

Technical Specifications

Specification Details
CO2 Measurement Range
  • T8100/T8200/T8300: 0 to 2000 ppm
  • T8100/T8200/T8300 - 5P models: 0 to 5000 ppm
  • T8200 (10P models): 0 to 10,000 ppm
  • T8200 (20P models): 0 to 20,000 ppm
CO2 Accuracy 30ppm or 3% of the reading shown, whichever is higher*
CO2 Sensing Method Non-dispersive infrared (NDIR) absorption, Gold-plated optics
Temperature Sensor Type Passive Thermistor (NTC 10 K W) on non-BACnet versions
Active Temperature Range 32F to 122F (0C to 50C)
Active Temperature Accuracy 0.8C @ 22C
RH Sensing Element Capacitive polymer sensor
RH Range 0% to 99% RH (non-condensing)
RH Accuracy (25C) 2.5% RH (20 to 80% RH); 3.5% RH (<20% and >80% RH)
Power Supply Requirements 18-30 VAC RMS, 50/60 Hz, or 10.8 to 42 VDC, polarity protected
Power Consumption Typical 0.7 W at 24V AC RMS
Signal Update Every 5 seconds
CO2 Warm-up Time < 2 minutes (operational); 10 minutes (maximum accuracy)
Operating Conditions 32F to 122F (0C to 50C); 0 to 95% RH, non-condensing
Storage Conditions -40F to 158F (-40C to 70C)
Output Options
  • Analog: Dual simultaneous 0-10 V (100 W output impedance) and 4-20mA (RL max 500 W)
  • BACnet: MS/TP, RS485 (38400 or 9600 baud rates)
Models
  • T8100: Single channel sensor, ABC Logic
  • T8200: Dual channel sensor, enhanced stability/accuracy
  • T8300: Single channel sensor with pitot tube kit for duct measuring, ABC Logic
Dimensions (Smaller Enclosure) 81.4 mm x 86.4 mm
Warranty 24 months on mechanical defects

2411041546_Amphenol-T8200-E-D-GN-5P-R_C17369725.pdf
