HARTING 09320403101 - Multi-Circuit-Wire-Crimping/Signal-Power-Transmission - PC 41Pin 16A Han EEE Heavy Duty Connector Insert
HARTING 09320403101 - Multi-Circuit-Wire-Crimping/Signal-Power-Transmission - PC 41Pin 16A Han EEE Heavy Duty Connector Insert
HARTING 09320403101 - Multi-Circuit-Wire-Crimping/Signal-Power-Transmission - PC 41Pin 16A Han EEE Heavy Duty Connector Insert
HARTING 09320403101 - Multi-Circuit-Wire-Crimping/Signal-Power-Transmission - PC 41Pin 16A Han EEE Heavy Duty Connector Insert
HARTING 09320403101 - Multi-Circuit-Wire-Crimping/Signal-Power-Transmission - PC 41Pin 16A Han EEE Heavy Duty Connector Insert
HARTING 09320403101 - Multi-Circuit-Wire-Crimping/Signal-Power-Transmission - PC 41Pin 16A Han EEE Heavy Duty Connector Insert
Specifications
Model Number :
09320403101
Termination Method :
Crimp Connection
Price :
USD 100-10000/Piece
Connector Series :
Han® EEE
Supply Ability :
1/piece in stock
Product Model :
HARTING 09320403101
Brand Name :
HARTING
Housing Size Compatibility :
Han® 16B
Payment Terms :
T/T
Product Type :
Heavy-Duty Connector Female Insert
Rated Current :
16 A
MOQ :
1
Delivery Time :
3-7
Rated Voltage :
500 V
Packaging Details :
50*50*50mm
Number of Contacts :
40 Contacts + PE
Certification :
3C
Place of Origin :
Germany
Description
HARTING 09320403101 - Multi-Circuit-Wire-Crimping/Signal-Power-Transmission - PC 41Pin 16A Han EEE Heavy Duty Connector Insert
Han® 3A Surface-Mount Housing

The 09320403101 is a Han® 3A surface-mount housing (top entry, M20 thread, single lever), manufactured from die-cast aluminum with IP65 protection rating and operating temperature range of -40°C to +125°C in gray (RAL 7037). This housing mates with Han® 3A inserts (3-24 contacts, 10-40A) for modular heavy-duty hookup applications.

Application & Advantages

Designed for compact machine and cabinet wiring, this housing accommodates power and signal inserts in space-constrained applications such as small robots, CNC auxiliaries, conveyor drives, and process skids. The combination of IP65 rating and cast aluminum construction provides excellent protection in industrial environments, while the M20 thread accommodates armored cable connections.

Product Specifications
Parameter Specification
Manufacturer HARTING Technology Group
Part Number 09320403101
Product Type Female Insert without Contacts
Series Han® EEE
Gender Female
Number of Positions 40 + Ground (PE)
Size 16B
Rated Voltage 500V
Rated Current 16A
Operating Temperature -40°C ~ 125°C
