32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management
32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management
32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management
32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management
Specifications
Brand Name :
KRONZ
Model Number :
KA3200
Certification :
CE
Place of Origin :
Guangzhou,China
MOQ :
5 pieces
Price :
Negotiable
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
100000 pieces per month
Delivery Time :
5-8 working days
Packaging Details :
Paper box packing
Model :
Distributed I/O module
Name :
32 channels digital input module
Current Consumption :
45mA
Number of Input Channel :
32
Input :
PNP
Input Current :
3mA
Description

Remoted I/O Module 32 Channels Digital Input Module PNP for Energy Management


Application in energy management:

Energy management in factories is crucial to reducing costs and saving energy and reducing emissions. Distributed I/O modules can be used to collect data from various energy devices (such as electricity meters, water meters, and gas meters) to achieve real-time monitoring and analysis of energy consumption. Through refined management of energy data, enterprises can formulate reasonable energy-saving strategies and reduce energy costs.


Features:

  • 32 Isolated Digital Input Channels

  • PNP (Sourcing) Logic – Compatible with +24V industrial sensors/PLC systems.

  • High-Density Design – Saves space in control cabinets.

  • Wide Input Voltage Range: 10-30V DC per channel (adjustable threshold).

  • Remote Monitoring & Control

  • Modbus RTU/TCP, PROFIBUS, or Ethernet/IP support (varies by model).

  • Real-time Data Logging for energy consumption tracking.

  • Industrial-Grade Reliability

  • Operating Temperature: -20°C to +60°C (extended range optional).

  • Protection: Surge suppression, reverse polarity protection, and channel-level diagnostics.

  • Easy Integration

  • DIN Rail Mounting (standard 35mm).

  • LED Indicators per channel for status monitoring.

Technical Data

Product model
KA3200
Product Name 32 channels digital input module
Power Specification
Current Consumption 45mA
Input Voltage 24VDC
Allowed Range 24VDC(±25%)
Output Characteristics
Number of Output Channels 32
Input Single Type PNP
Input Rated Voltage
24 VDC(±20%)
Input logic 1 signal 15~30V
Input logic 0 signal -3~3V
Debounce time Configurable:1~10ms,Default value 3ms
Typical value of input current 3mA
Isolation and withstand voltage 500V
Isolation method Optocoupler isolation
Physical Property
Dimension 100mmx69.65mmx24mm
Operation Temperature 0~55℃
Storage temperature -25~85℃
Protection Grade IP20


Module installation diagram Module disassembly diagram
32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management 32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management


Application Scenarios

32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management

Adapter connected to power supply

32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management


Company Profile

32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management

32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management

32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management

32 Channels Remote I/O Module 45mA Digital Input Module PNP For Energy Management
