Linear Shaking Water Bath RWS-48
Linear Shaking Water Bath RWS-48
Linear Shaking Water Bath RWS-48
Linear Shaking Water Bath RWS-48
Specifications
Place of Origin :
Shanghai, China
Brand Name :
Senova
Certification :
CE
MOQ :
1 unit
Price :
Negotiation
Packaging Details :
Carton with pallet
Delivery Time :
Approx. 10 working days
Payment Terms :
T/T
Supply Ability :
500 units/month
Model Number :
RWS-48
Product :
Linear Shaking Water Bath
Capacity :
170 Liters
Temperature Range :
Ambient to 100°C
Load Capacity :
50x250ml 30x500ml,or, 21x1000ml
Display :
LCD Display
Temperature Control :
Digital PID Controller
Chamber Material :
Stainless Steel 316L
Power Supply :
220V/50Hz,110V/60Hz
Description
Linear Shaking Water Bath RWS-48
Main Features
  • SS316 chamber with powder coated mild steel exterior
  • SUS316 lid, flask shaking platform, universal spring shaking platform and flask clamps
  • Gabled lid cover to minimize eat loss and evaporation
  • Drainage valve on the left side for water draining, cleaning and sterilization
  • P.I.D environmental scanning micro-processing controller with acoustic & visual alarm
  • Ideal temperature control linear with small fluctuation and temperature uniformity
  • LCD display of set and working parameters
  • Operating parameter memory function avoids monotonous operations
  • Automatic stop of heating and alarm is activated when working temperature deviates from the set value by 3℃
  • Dual over-temperature protection with automatic heating cut-off in case of low water level/over temperature for heating parts or sample over-temperature
  • Dry heating prevention
  • Power failure memory recovery retains preset parameters during a power failure and restarts unit automatically after the power is restored.
  • 999.59 hour timer setting with LCD display of remaining time.
  • Automatic stop at the end of timing with acoustic and visual alarm is activated
Technical Data
Control P.I.D.
Display LCD (Real-time display of set and working parameters)
Convection Mode Forced Convection
Shaking Mode Linear(Reciprocating)
Drive Single-shaft drive
Speed Range(rpm) 20-200
Speed Accuracy ±1rpm
Orbit Φ25mm
*Max. Capacity(flask) 50x250ml,30x500ml,or, 21x1000ml
Flask Platform Size(mm) 780x590x10(Standard)
Spring Platform Size(mm) 780x590x80(Optional)
Timing Range 0-999.59 hr
Environment Temp. 15℃-35℃
Temp. Resolution ±0.1
Temp. Control Range RT~100℃
Temp. Control Accuracy ±0.1℃(constant temperature status)
Temp. Uniformity ±0.2℃
Platform Qty. 1
N.W./G.W. (Kg) 133/195
Chamber Dimensions(DxWxH,mm) 940x660x275
Capacity(L) 170
Overall Dimensions(DxWxH,mm) 1240x700x830
Packing Size(LxW,H,cm) 129x75x93
Power(W) 4000
Power Supply AC 200-240V/50-60Hz. Optional: AC110V/60Hz
