3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
Specifications
Brand Name :
huihao
Model Number :
Capacitor Discharge Insulation Welding Pins
Certification :
ISO
Place of Origin :
China
MOQ :
Negotiable
Payment Terms :
L/C,T/T,Western Union,paypal
Supply Ability :
5000000pcs per 30 days
Delivery Time :
5-8 work days
Packaging Details :
1. 1000 pcs / 2000 pcs/ 3000 pcs per carton 2. 36 cartons per pallet 3. or according to your requirement.
Product name :
Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
brand :
Huihao Custom
material :
Low carbon steel or stainless steel
pin dia :
0.135" / 3.4mm
surface treatment :
copper plated, galvanized
base dia :
1" / 25mm or 1-3/16"/30mm
samples :
Free
length :
as your request
Description

3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation


Product Description Of Cupped Head Capacitor Discharge Weld Pins:


Cupped Head Capacitor Discharge Weld Pins are widely used for metal air duct insulation work.

The pins simplify the installation of "Duct Liner" or other insulation materials to duct work or to other heating, ventilating or air conditioning sheet metal configurations and housings.

Cupped Head Capacitor Discharge Weld Pins are widely accepted as labor saving fasteners in the thermal and acoustical insulation markets for use in industrial and commercial applications.


If you are in need of Cupped Head Capacitor Discharge Weld Pins for duct insulation work, please feel free to ask me a price or sample, our cup head weld pins are with good quality, any my email address is cherry@huihaomesh.com


3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation

Head Material: Low carbon steel or stainless steel

Head Surface Finish: galvanized is standard

Head Edge: Beveled edge washer to prevent cutting of insulation material. Flat edge washer style also standard.

Head Diameter (WD): 1" (25mm), 1-3/16" (30mm)

Pin Material: Low carbon steel or stainless steel

Pin Surface Finish: galvanized is standard, copper plating is available upon special request.

Pin Diameter (D): 12Gauge (2.7mm), 11Gauge (3.0mm), 10Gauge (3.4mm)

Pin Length (L): As your request
3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation

3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation

3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation


Package Of Cupped Head Capacitor Discharge Weld Pins:



Item Cupped Head Capacitor Discharge Weld Pins
Brand HUIHAO Costom
Size 25mm, 38mm, 50mm, 75mm, 100mm, 130mm, etc.
Package

1. 1000 pcs / 2000 pcs/ 3000 pcs per carton

2. 36 cartons per pallet
3. or according to your requirement.


3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation

Installation Introduction Of Cupped Head Capacitor Discharge Weld Pins:


3.4mm Cupped Head Capacitor Discharge Weld Pins For Metal Air Duct Insulation
Recommended for Pin length before welding
1/2" insulation(all densities) 12.67mm
1" insulation(1-1/2"ib density) 17.63mm
1" foam 25.55mm
1"insulation(3ib densities) 23.72mm
1-1/2" insulation(all densities) 28.42mm
2"insulation(1-1/2"-2" ib density) 37.95mm
2"insulation(3ib densities) 48.77mm
3"insulation(all densities) 69.85mm
4" insulation(all densities) 95.00mm


FAQ Of Cupped Head Capacitor Discharge Weld Pins:


1. Are you manufacture or trader?

  • We are the manufacture and we sell what we make.

2. Do you support product customization?

  • Yes, the material, the size, the length all could be customizied according to your request.

3. Can you accept small orders?

  • Yes, for common size, we could accept small orders.

4. Can i get samples?

  • we can send you samples.

5. What is your advantages for the cup head weld pins?

  • Competitive price: we sale what we manufacture.
  • Excellent quality: we have rich experience, our products are in line with international standard.
  • Good after-sale service: we offer good after-sale service for each order.
  • Our cup head weld pins are consist in price, quality and delivery service.
