display parameters

Panel size

30 inches.

Panel type

OLED

display area

664.29Mm * 373.48mm

external dimensions

676.09Mm × 387.48mm × 1.6mm (width × height × thickness)

transmittance

43%

viewing angle

178 °, 178 °

static contrast

100000:1 (Typ.) Transmission

Dynamic Contrast

200000:1 (Typ.) Transmission

patchwork

Unilateral 5.9mmm, bilateral 12mm, overall unilateral stitching 5.9/5 9/5.9/8.1 (left/right/top/bottom)

screen scale

16:9

brightness

200-600 (nits)

Best resolution

1366*768

Screen life

≥ 30000 hours

power

≤ 150W

Display color

10-Bit, 1.07B (1B = 1 billion)

Speaker

8Ω/5W * 2

screen gross weight

Screen weight 1.04kg

Gross weight of the whole machine

to be determined

environment

Working temperature 1 ℃~ 45 ℃

working humidity

30%~80%

running time

18 hours x 7 days

Ambient height

(Altitude) 0~ 5000m

response time

8ms

working voltage

100V-240VAC, 50/60Hz

Fitting method

frame sticker

Fitting method (optional)

Full fit

Driver Board

input interface

HDMI IN

USB

USB 2.0

DP

DP IN

weight

0.4Kg

Control signal IN

RS232 serial port (RJ45)

Control signal OUT

RS232 serial port (RJ45)

function

With splicing function

protect

Anti-afterimage, anti-burn, repair function

Touch screen parameters: capacitance optional

touch technology

Capacitive touch technology

positioning accuracy

3Mm

Installation method

Built-in integrated

writing method

Finger ≥ 5mm

touch points

10 touch writing

Writing screen medium

5-8Mm tempered high transparency glass

response speed

≤ 5ms

computer driven

drive-free

mode of communication

USB

service life

≥ 60 million times

printer configuration

Print method

Thermal line printing

Paper type

Continuous thermal paper, die-cut label paper

resolution

203Dpi (8dot/mm)

Paper width

24-58Mm (adjustable)

Print speed

MAX.170mm/s

roll diameter

Max. 50mm

effective print width

48Mm

paper thickness

0.053-0.09mm(receipt)/0.10-0.15mm(label)

interface

Serial, USB

Paper loading method

Easy Loading Paper

one-dimensional barcode

UPC-A, UPC-E, EAN8, EAN13, code39, ITF, CODEBAR, CODE128, CODE93

Automatic cutter

Full and half cuts (via instruction)

2D barcode

QR code, PDF417

Chinese

GBK: 16x16, 24x24

power supply

DC12-24V/2A (peak > 4A)

Western

ASCII: 8x16, 9x17, 9x24, 12x24

QR code configuration

image sensor

640X480 CMOS

Field of view angle

Horizontal 60 °, vertical 48 °

lighting

White LED (6500K)

Communication interface

TTL/RS-232, USB, RS485

reading code system

2D

PDF417, Data Matrix, QR Code

Appearance dimension (mm)

64.8 (W) × 60.5 (D) × 32.7 (H) mm

reading code system

1D

Interleaved 2 of 5, ISBN, Code 93, Code 11, UCC/EAN-128 GS1 Databar, Matrix 2 of 5, Industrial 2 of 5, Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Standard 2 of 5, MSI-Plessey, GS1composite code, etc

interface

USB, TTL233, RS232, RS485 and other interfaces,

Interface form: FPC, SH 1.0 connector, Mirco USB optional

reading accuracy

≥ 5mil

weight

20G

Alipay

30-150Mm (based on the front end of the lens, the screen size of the mobile phone is 5.2 inches)

fall

Can withstand a 1.2-meter drop to the concrete floor

Bus code

50-120Mm (based on the front end of the lens, the screen size of the mobile phone is 5.2 inches)

working voltage

5V DC ± 10% (reserve 3.3-16V wide voltage input)

sign contrast

≥ 20%

Rated current

(Typical) Less than 190mA (5V input) Less than 100mA (10V input)

barcode sensitivity

Tilt ± 55 °, Deflect ± 55 °, Rotate 360 °

vibration

2000 G, 0.7 ms, half sinus, 3 axes

Card reader configuration

antenna energy output

Antenna surface electromagnetic strength (Hmax) ≤ 7.5A/m rms

Reading time

< 1s

Electromagnetic intensity at the maximum reading distance in the normal direction of the antenna surface (Hmax ≥ 1.5A/m rms)

card reading distance

0~ 3Cm

operating frequency

13.56MHz ± 7KHz

interface

USB2.0

relative humidity

<90%

Storage and transportation relative humidity

20%~93%

atmospheric pressure

86Kpa~ 110Kpa

Mean Time Without Failure (MTBF)

> 5000h

Power supply method

USB powered

weight

< 0.37Kg

Support for development languages

C++, BS, C #, etc

external dimensions

190Mm (L) X125mm (W) X40mm (H)

Applicable operating system

Windows XP/7/8/10; Kydroid Desktop Operating System (Feiteng, Kunpeng, Loongson, HiSilicon Kirin, Shenwei, Haiguang, Zhaoxin, AMD64) V10: win the bidding Kirin Desktop Operating System (Feiteng, Kunpeng, Loongson, Shenwei, Haiguang, Zhaoxin): Tongxin Desktop Operating System (Feiteng, Kunpeng, Loongson, HiSilicon Kirin, Zhaoxin) V20; Hongqi Linux Desktop Operating System (Loongson, Shenwei); Kirin Xin'an Operating System (Feiteng, Kunpeng, Loongson, Shenwei, Haiguang, Zhaoxin); Puhua Desktop Operating System (Loongson, Shenwei); Ubuntu18.04 (X86); Cent0S 8 (x86)

PC configuration (optional)

main board

Intel Core

CPU

4th generation/6th generation/7th generation/8th generation/10th generation - Core i3/i5/i7 (optional)

Memory

4G/8G/16G-DDR3 (optional)

Hard disk

SSD120G/240G/480-HDD500G/1T/2T (optional)

nuclear display

Intel HD Graphics 4000

Backplane I/O

1 × DC_IN power interface, 1 × HDMI interface, 1 × VGA interface, 2 × USB3.0 interface, 1 × LAN_RJ interface, 2 × USB2.0 interface, 1 × Mic (input), 1 × PHONE (output)

Operating System

Windows 7/Windows 10 operating system

Android configuration (optional)

Main board model

3568/3288/3588

Memory

2G/4G/8G optional

storage

16G/32G/64G/128G optional

interface

1 × USB2.0, 1 × USB3.0, 1 × HDMI_OUT, 1 × LAN_RJ, 1 × WIFI

Packing and packing list

Package size

Honeycomb box: 93 * 71 * 179CM

Air box: 65 * 66 * 168CM

Weight information

Bare metal weight: 55KG

Packaging weight:

Bare metal + air box: 100KG

Bare metal + honeycomb box: 80KG

name

With PC/Android

Specifications

quantity

Remarks

transparent display

30 inch OLED transparent screen

1 piece

system

Customized according to actual needs (built-in)

1 set

remote control

Universal version (without battery)

1

Power cord

National standard 1.5 meters

Article 1

HDMI extension cable Note ②

optional

Article 1

Touch the USB extension cable Note ②

optional

Article 1

HDMI signal cable Note ②

optional

Article 1

Warranty card certificate

Chinese version

1 sheet

Note: HDMI extension cable, HDMI cable and touch USB extension cable are optional items. The final packing list is subject to the actual shipment of the customer. You can choose whether to configure the extension cable according to customer needs. Note that the selection will incur corresponding costs. Please confirm the price for shipment.
