display parameters

Panel size

30 inches.

Panel type

OLED

display area

664.29Mm * 373.48mm

external dimensions

676.09Mm × 387.48mm × 1.6mm (width × height × thickness)

transmittance

43%

viewing angle

178 °, 178 °

static contrast

100000:1 (Typ.) Transmission

Dynamic Contrast

200000:1 (Typ.) Transmission

patchwork

Unilateral 5.9mmm, bilateral 12mm, overall unilateral stitching 5.9/5 9/5.9/8.1 (left/right/top/bottom)

screen scale

16:9

brightness

200-600 (nits)

Best resolution

1366*768

Screen life

≥ 30000 hours

power

≤ 150W

Display color

10-Bit, 1.07B (1B = 1 billion)

Speaker

8Ω/5W * 2

screen gross weight

Screen weight 1.04kg

Gross weight of the whole machine

to be determined

environment

Working temperature 1 ℃~ 45 ℃

working humidity

30%~80%

running time

18 hours x 7 days

Ambient height

(Altitude) 0~ 5000m

response time

8ms

working voltage

100V-240VAC, 50/60Hz

Fitting method

frame sticker

Fitting method (optional)

Full fit

Driver Board

input interface

HDMI IN

USB

USB 2.0

DP

DP IN

weight

0.4Kg

Control signal IN

RS232 serial port (RJ45)

Control signal OUT

RS232 serial port (RJ45)

function

With splicing function

protect

Anti-afterimage, anti-burn, repair function

Touch screen parameters: capacitance optional

touch technology

Capacitive touch technology

positioning accuracy

3Mm

Installation method

Built-in integrated

writing method

Finger ≥ 5mm

touch points

10 touch writing

Writing screen medium

5-8Mm tempered high transparency glass

response speed

≤ 5ms

computer driven

drive-free

mode of communication

USB

service life

≥ 60 million times

PC configuration (optional)

main board

Intel Core

CPU

4th generation/6th generation/7th generation/8th generation/10th generation - Core i3/i5/i7 (optional)

Memory

4G/8G/16G-DDR3 (optional)

Hard disk

SSD120G/240G/480-HDD500G/1T/2T (optional)

nuclear display

Intel HD Graphics 4000

Backplane I/O

1 × DC_IN power interface, 1 × HDMI interface, 1 × VGA interface, 2 × USB3.0 interface, 1 × LAN_RJ interface, 2 × USB2.0 interface, 1 × Mic (input), 1 × PHONE (output)

Operating System

Windows 7/Windows 10 operating system

Android configuration (optional)

Main board model

3568/3288/3588

Memory

2G/4G/8G optional

storage

16G/32G/64G/128G optional

interface

1 × USB2.0, 1 × USB3.0, 1 × HDMI_OUT, 1 × LAN_RJ, 1 × WIFI

Packing and packing list

Package size

Honeycomb box: 76 * 50 * 125CM

Air box:/

Weight information

Bare metal weight: 55KG

Packing weight (bare metal + honeycomb box): 85KG

name

With PC/Android

Specifications

quantity

Remarks

transparent display

30 inch OLED transparent screen

1 piece

system

Customized according to actual needs (built-in)

1 set

remote control

Universal version (without battery)

1

Power cord

National standard 1.5 meters

Article 1

HDMI extension cable Note ②

optional

Article 1

Touch the USB extension cable Note ②

optional

Article 1

HDMI signal cable Note ②

optional

Article 1

Warranty card certificate

Chinese version

1 sheet

Note: HDMI extension cable, HDMI cable and touch USB extension cable are optional items. The final packing list is subject to the actual shipment of the customer. You can choose whether to configure the extension cable according to customer needs. Note that the selection will incur corresponding costs. Please confirm the price for shipment.
