SUS 304 316 316L Stainless Steel Crimped Woven Wire Mesh Screen For Sand Stone Sieve Screen Mining
SUS 304 316 316L Stainless Steel Crimped Woven Wire Mesh Screen For Sand Stone Sieve Screen Mining
SUS 304 316 316L Stainless Steel Crimped Woven Wire Mesh Screen For Sand Stone Sieve Screen Mining
SUS 304 316 316L Stainless Steel Crimped Woven Wire Mesh Screen For Sand Stone Sieve Screen Mining
Specifications
Brand Name :
Qijie
Model Number :
Crimped Wire Mesh
Certification :
Crimped Wire Mesh
Place of Origin :
China
MOQ :
10pcs
Payment Terms :
L/C, T/T
Supply Ability :
1000rolls/month
Delivery Time :
15-18days
Packaging Details :
wood case
Aperture :
25mm
Application :
Security Screen
Color :
Silver
Features :
High Strength, Corrosion Resistance
Length :
15m
Material :
aluminum
wire diameter :
2mm
Description

SUS 304 316 316L Stainless Steel Crimped Woven Wire Mesh Screen For Sand Stone Sieve Screen Mining

Crimped wire mesh is also known as pre-crimped wire mesh or plaited wire mesh.
Types of crimped wire mesh: lock-crimped,inter-crimped,double-crimped, flat top crimped,multi-crimped or plain weave.
Raw materials of crimped wire mesh: stainless steel wire, Manganese steel wire(65Mn), low carbon steel wire, copper wire, Titanium wire, etc.


SUS 304 316 316L Stainless Steel Crimped Woven Wire Mesh Screen For Sand Stone Sieve Screen Mining

Crimped Wire Mesh Application
​1/Stainless steel crimped wire mesh for screening / sieving, commonly used in food processing industry, such as barbeque mesh.
2/Powder coated, brass or stainless steel crimped wire mesh can be used in decoration,such as exterior wall.
3/High tensile steel crimped wire mesh generally used in mine industry, such as quarry screen mesh.
4/Flat top crimped wire mesh used for pig raising.
5/Crimped wire mesh for fan cover.
6/Crimped wire mesh used as fence.

SUS 304 316 316L Stainless Steel Crimped Woven Wire Mesh Screen For Sand Stone Sieve Screen Mining

Part specs of crimped wire mesh

Aperture Aperture Tolerance (mm) Wire Dia. Edge Length (mm) Weight
mm Min. Max. mm Min. Max. KG/SQM
101.60 98.55 104.65 12.70 12.70 50.80 17.92
88.90 86.23 91.57 12.70 12.70 44.45 20.16
76.20 73.91 78.49 12.70 12.70 38.10 23.04
63.50 61.60 65.41 12.70 12.70 31.75 26.88
63.50 61.60 65.41 9.19 9.19 31.75 14.76
57.15 55.44 58.86 9.19 9.19 28.58 16.17
50.80 49.28 52.32 12.70 12.70 25.40 32.26
50.80 49.28 52.32 11.10 11.10 25.40 25.28
50.80 49.28 52.32 9.19 11.10 25.40 17.88
50.80 49.28 52.32 7.92 7.92 25.40 13.57
44.45 43.12 45.78 9.19 9.19 22.23 20.00
44.45 43.12 45.78 7.92 7.92 22.23 15.21
41.28 40.04 42.51 9.19 9.19 20.64 21.25
41.28 40.04 42.51 7.92 7.92 20.64 16.19
38.10 36.69 39.24 9.19 9.19 19.05 22.68
38.10 36.69 39.24 7.92 7.92 19.05 17.31
38.10 36.69 39.24 7.19 7.19 19.05 14.49
31.75 30.80 32.70 9.19 9.19 15.88 26.20
31.75 30.80 32.70 7.92 7.92 15.88 20.08
31.75 30.80 32.70 7.19 7.19 15.88 16.85
28.58 27.72 29.43 7.92 7.92 14.29 21.83
28.58 27.72 29.43 7.19 7.19 14.29 18.35
25.40 24.64 26.16 7.92 7.92 12.70 23.91
25.40 24.64 26.16 7.19 7.19 12.70 20.14
19.05 18.48 19.62 5.72 5.72 9.53 16.78
15.88 15.40 16.35 4.50 4.50 7.94 12.62
11.00 10.67 11.33 4.00 4.00 5.50 13.55
10.00 9.70 10.03 4.00 4.00 5.00 14.51
8.00 7.76 8.24 4.00 4.00 4.00 16.93
6.35 6.16 6.54 2.67 2.67 3.18 10.04
6.30 6.11 6.49 2.50 2.50 3.15 9.93
4.00 3.88 4.12 2.00 2.00 2.00 9.31
3.00 2.91 3.09 2.00 2.00 2.00 11.17
2.00 1.94 2.06 1.50 1.50 1.50 8.99
