Aluminum Crimped Wire Mesh Manufacturer In China
Aluminum Crimped Wire Mesh Manufacturer In China
Aluminum Crimped Wire Mesh Manufacturer In China
Aluminum Crimped Wire Mesh Manufacturer In China
Aluminum Crimped Wire Mesh Manufacturer In China
Aluminum Crimped Wire Mesh Manufacturer In China
Aluminum Crimped Wire Mesh Manufacturer In China
Aluminum Crimped Wire Mesh Manufacturer In China
Specifications
Brand Name :
Qijie
Model Number :
Crimped Wire Mesh
Certification :
Crimped Wire Mesh
Place of Origin :
China
MOQ :
10pcs
Payment Terms :
L/C, T/T
Supply Ability :
1000rolls/month
Delivery Time :
15-18days
Packaging Details :
wood case
Aperture :
25mm
Application :
Security Screen
Color :
Silver
Features :
High Strength, Corrosion Resistance
Length :
15m
Material :
aluminum
wire diameter :
2mm
Description

65Mn screen mesh sold hot in Mideast market

Crimped wire mesh also called square wire mesh is cloth made from wire strands. The wires that make up wire mesh run parallel to the width of the roll (cross wires) and parallel to the length (line wires). The cross and line wires are interwoven. That is, the wires cross over and under each other. Wire Mesh can be woven in a number of different styles depending on the material type, wire diameter, and opening size. Crimped wire mesh is available in rolls, sheets or panels, and cut-to-size.
Screen mesh is widely used in industry, agruculture, crusher, building, house fencing and so on.
1. Material:
High carbon steel wire, low carbon steel wire, galvanized wire, stainless steel wire and other metal wires.


2. Feature:
It has fine features of neat & precise, sturdy structure, durable& strongly rust-resistant and fine anti-corrosiveness.


3.Packaging:
Wrapped with moister-proof paper, Then covered with Hessian cloth



4.Application:
Screening in mine, coal factory, construction and other industries.used as window
screening, safety guards in machinery enclosures, also used in filtering liquid and gas, sieving grain.


5.Specification:

Item

wire diameter
mm

open size
mm

width
m

length
m

weight
kg

1

2

3

1.5

2

32

2

3

5

1.5

2

42.6

3

4

8

1.5

2

51.13

4

4.5

12

1.5

2

46.77

5

5

16

1.5

2

45.52

6

5.5

18

1.5

2

49.37

7

6

20

1.5

2

52.7

8

6

22

1.5

2

48.96

9

6.5

24

1.5

2

52.87

10

6.5

27

1.5

2

48.12

11

7

30

1.5

2

50.63

12

8

50

1.5

2

42.29

13

12

75

1.5

2

64

No.

Grade

Chemical Composition

Wire diameter

C

Si

Mn

mm

1

45

0.42-0.50

0.17-0.37

0.50-0.80

2.0-6.0

2

50

0.47-0.55

0.17-0.37

0.50-0.80

3

55

0.52-0.60

0.17-0.37

0.50-0.80

4

60

0.57-0.65

0.17-0.37

0.50-0.80

5

65

0.62-0.70

0.17-0.37

0.50-0.80

6

70

0.67-0.75

0.17-0.37

0.50-0.80

7

65Mn

0.62-0.70

0.17-0.37

0.90-1.20

2.0-14.0


6. Workshop:

Aluminum Crimped Wire Mesh Manufacturer In China

Aluminum Crimped Wire Mesh Manufacturer In China
