SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
SAE 100 R15 Hydraulic Hose , 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe
Specifications
Brand Name :
Kelong
Model Number :
SAE 100 R15 1/4
Certification :
ISO9001 / IRIS
Place of Origin :
China
Payment Terms :
L/C, T/T, Paypal
Supply Ability :
16,5600 meters /months
Delivery Time :
7-15 days
Tube :
Synthetic rubber layer, steel wire wrapping layer
Reinforcement :
Multi-layer high-strength steel wire winding
Cover :
Abrasion and ozone resistant synthetic rubber
Temperature range :
-40°C to 121°C / -40°F to +250°F
Note :
Various covers available
Applications :
Petroleum based hydraulic oil
Name :
SAE 100 R15 Hydraulic Hose
Description

SAE 100 R15 1/4 Inch Suction Steel Wire Braided Hydraulic Hose Pipe With Oil Resistant Tube

Application:
This hose is very popular in high pressure working conditions and it is suitable for petroleum-based hydraulic oils.
Features:
1,The tube is made from black oil resistant synthetic rubber, making the hose widely used in delivering petroleum-based hydraulic oils.
2,The reinforcement is made from multiple layers of high tensile and high strength thick spiraled steel wire in alternating direction, making the hose have very high working pressure.
3,The cover is made from high quality synthetic rubber, making the hose resistant to abrasion, corrosion, weather, ozone, aging and cut.
Material:
Tube: high quality black oil resistant synthetic rubber.
Reinforcement: multiple layers of high tensile and high strength thick spiraled steel wire in alternating direction.
Cover: high quality abrasion, corrosion and weather resistant synthetic rubber.
Working temperature range: -40°C to +121°C
Working pressure: 42 MPa.
Proof pressure: 84 MPa.
Min burst pressure: 168 MPa.

SAE 100 R15 steel wire spiraled hydraulic hose

Hose code

Size

Dash
size

ID

WD

OD

Worki ng
pressure

Proof pressure

Mi n burst
pressure

Min
bending
radius

Weight

mm

inch

min

max

max

max

MPa

psi

MPa

psi

MPa

psi

mm

kg/m

SAE100R15-01

10

3/8

6

9.3

10.1

20.3

23.3

42

6090

84

12180

168

24360

150

0.8

SAE100R15-02

12.7

1/2

-8

12.3

13.5

24

26.8

42

6090

84

12180

168

24360

200

0.95

SAE100R15-03

19

3/4

-12

18.6

19.8

32

36.1

42

6090

84

12180

168

24360

265

1.85

SAE100R15-04

25

1

-16

25

26.4

38.9

42.9

42

6090

84

12180

168

24360

330

2.9

SAE100R15-05

31.5

1-1/4

-20

31.4

33

48.4

51.5

42

6090

84

12180

168

24360

445

4.2

SAE100R15-06

38

1-1/2

-24

37.7

39.3

56.3

59.6

42

6090

84

12180

168

24360

530

5.6
