Specifications
Brand Name :
Kelong
Model Number :
EN856 4 SH
Certification :
ISO9001 / IRIS
Place of Origin :
China
Payment Terms :
L/C, T/T, Paypal
Supply Ability :
16,5600 meters /months
Delivery Time :
7-15 days
Tube :
Synthetic rubber layer, steel wire wrapping layer
Reinforcement :
Multi-layer high-strength steel wire winding
Cover :
Abrasion and ozone resistant synthetic rubber
Temperature range :
-40°C to 121°C / -40°F to +250°F
Note :
Various covers available
Applications :
Petroleum based hydraulic oil
Description
EN 856 4SH steel wire spiraled hydraulic hose has higher working pressure performance, so it is perfectly suitable for extremely high pressure working conditions. It has excellent performance in delivering petroleum-based hydraulic fluids in the working temperature of -40 °C to +100 °C
Features:
◆ work well in conveying oils
◆ resistant to abrasion, corrosion and oil
◆ resistant to high pressure
◆ corrosion, abrasion, weather and ozone resistant synthetic rubber and the appearance is cloth impression rubber.

Material:
Tube: black synthetic rubber
Reinforcement: four layers of high tensile and high strength spiraled steel wire
Cover: high quality black synthetic rubber
Working temperature range: -40℃ to +100℃
Commodity Specification
SAE 100 R1,R2,R6,R7,R8,R9,R12,R13,R14,R15,R16,R17
DIN EN853 1SN,2SN,1ST,2ST
DIN EN856 4SH 4SP
DIN EN857 1SC,2SC
The specification of EN 8564SH steel wire spiraled hydraulic hose
Hose code Size Dash size ID WD OD Working pressure Proof pressure Min burst pressure Min bending
radius		 Weight
mm inch min max min max min max MPa Psi MPa Psi MPa Psi mm kg/m
EN8564SH-01 19 3/4 -12 18.6 19.8 27.6 29.2 31.4 33.0 42.0 6090 87 12180 168 24360 280 1.70
EN8564SH-02 25 1 -16 25.0 26.4 34.4 36.0 37.5 39.9 38.0 5510 76 11020 152 22040 340 2.50
EN8564SH-03 31.5 1-1/4 -20 31.4 33.0 40.9 42.9 43.9 47.1 32.5 4710 65 9425 130 18850 460 3.00
EN85645H-04 38 1-1/2 -24 37.7 39.3 49.8 49.8 51.9 55.1 29.0 4205 58 8410 116 16820 560 3.60
EN8564SH-05 51 2 -32 50.4 52.0 64.2 64.2 66.5 69.7 25.0 3625 50 7250 100 14500 700 5.00
