Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Specifications
Brand Name :
HONGXINBAIYAO
Place of Origin :
Guangdong, China
MOQ :
1
Certification :
CE
Price :
$1200
Payment Terms :
T/T
Model Number :
BY-6050-W
Material :
SUS
Description

Dust-free Eco-friendly Low-energy-consumption Mini Wet Sandblasting Cabinet

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

MODEL
Overall dimensions
Cabin size
Inlet size
BY-9070-W
940(L)*950(W)*1700(H)mm
900*700*600mm
680*500mm
BY-9080-W
940(L)*1050(W)*1750(H)mm
900*800*650mm
680*580mm
BY-1010-W
1050(L)*1450(W)*1750(H)mm
1000*1000*750mm
700*650mm
BY-1212-W
1250(L)*1430(W)*1750(H)mm
1200*1200*800mm
800*750mm
BY-1515-W
1570(L)*1660(W)*1980(H)mm
1500*1500*900mm
1100*1050mm
Note: All equipment sizes for manual measurement, can allow 2-5 cm measurement error.

Product Overview

The mini small wet sandblasting machine is a compact, efficient, and environmentally friendly surface treatment device designed for small-batch processing, precision parts finishing, and DIY/light industrial applications. It integrates wet sandblasting technology with a miniaturized structure, making it ideal for small workshops, laboratories, jewelry processing, electronic component manufacturing, and small hardware part treatment. This machine delivers high-quality surface results while solving the dust and heat issues of traditional dry sandblasting, offering a clean, safe, and cost-effective solution for small-scale surface finishing needs.

Working Principle

The machine operates on the wet sandblasting principle: abrasive media (such as glass beads, fine aluminum oxide, or garnet) are mixed with water to form a uniform slurry. Compressed air accelerates the slurry through a precision nozzle, spraying it at high velocity onto the workpiece surface. The water in the slurry suppresses dust generation, cools the workpiece to prevent thermal deformation, and lubricates the abrasive to reduce friction. The used slurry is filtered and recycled via a small closed-loop system, minimizing waste and water consumption.

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption



Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption

Dust Free Eco Friendly Mini Wet Sandblasting Cabinet Low Energy Consumption
