AC Servo Motor Drive 210kgs Max Palletizing Weight 4 Axis Movement Palletizing Robot and Robotic Palletizer
AC Servo Motor Drive 210kgs Max Palletizing Weight 4 Axis Movement Palletizing Robot and Robotic Palletizer
AC Servo Motor Drive 210kgs Max Palletizing Weight 4 Axis Movement Palletizing Robot and Robotic Palletizer
AC Servo Motor Drive 210kgs Max Palletizing Weight 4 Axis Movement Palletizing Robot and Robotic Palletizer
Specifications
Brand Name :
AGMT
Model Number :
AGMT-SR210
Certification :
CE
Place of Origin :
Hefei, Anhui, China
MOQ :
One unit
Price :
26280
Payment Terms :
L/C,T/T
Supply Ability :
50 units/month
Delivery Time :
30-40 working days
Packaging Details :
Film wrapped and packed in wooden case
Robot HMI :
PLC
Product capacity :
400-600 packages/hour
Voltage :
3 phase/ 380V
A axis movement :
330 degree
Application :
Beverage , Food , Carton, Drum, bag etc.
Name :
Pick And Place Robot palletizer
Function :
Palletizing , stacking, placing etc.
Robot gripper type :
designed according to product
Description
AC Servo Motor Robot Palletizing Pick And Place In Chemical Industry
Brand Motor Robot Palletizing Low Cost Pick And Place In Chemical Industry
Brief Introduction
AGMT XY-SR series palletizing robot is a four-degree cylinder surface coordinate palletizing robot, primarily operated by horizontal movement axis, vertical movement axis, rotation foundation, and hand axis. The multilayer palletizing capability enables the fork to move items into storage. This equipment utilizes PLC touch screen and intelligent management systems, making it not only simple and easy to master but also reducing labor requirements.
Robotic Palletizing System Technical Parameters
Model No. AGMT-SR-210
Drive AC servo motor drive
Installation On floor
Max Palletizing Weight (contains weight of gripper) 210kgs
Handing Capacity 1700 Times/Hour
Movement Axis Normally 4 axes: A, B, C, D (can be 6 axis)
Movement scope A-Axis (Horizontal): 1500mm
B-Axis (Vertical): 2300mm
C-Axis (Body): 330°
D-Axis (Gripper): 330°
Location Accuracy ±0.5mm
Power 6.5KVA
Compressed Air 0.5Mpa
Robot Weight (not contains weight of gripper) 1150kgs (+/-10%)
Features
Palletizing robots from SAIMO can meet virtually any palletizing requirement. Thanks to a wide selection of end effectors, robotic palletizers provide maximum flexibility. Whether you need to handle cases, bags, pails, jugs, drums, or any other type of container, we can provide you with adapted, reliable and highly productive palletizers for small-, medium-, and large-scale production. With hundreds of palletizing robots sold worldwide, SAIMO has developed unique expertise in the manufacturing of fast and reliable robotic palletizers. Thanks to the high quality of ABB robots and the simplicity of their design, SAIMO palletizing robots are extremely reliable and require very little maintenance.
AC Servo Motor Drive 210kgs Max Palletizing Weight 4 Axis Movement Palletizing Robot and Robotic Palletizer
Function
  • Simple structure, low failure rate and convenient maintenance
  • Few main parts and accessories, low maintenance cost
  • Low power consumption, only 1/3 consumption of the same kind of mechanical stacker crane from other companies
  • Only need a little floor space, floor utilization ratio is high
  • Diverse gripper, flexibly adapt various palletizing requirements
Commission and After-sale Service
We make accurate factory layout design according to customer's factory size; if the customer needed, we could make workshop design with electric power, water supply, gas power, material storage, final storages, workers' restroom, etc. If customer need, we will send engineer for the commissioning service. 1-2 of our engineer will go to your factory to install and adjust the processing line to realize normal production at shortest time.
Installation Instructions
We will supply you the user manual and electrical drawing of all the machines for you to install the machines by yourself. If you think you cannot install the machines by yourself, we can send engineer to your factory for installing and debugging etc.
AC Servo Motor Drive 210kgs Max Palletizing Weight 4 Axis Movement Palletizing Robot and Robotic Palletizer
