CXJ-2 High Precision Automatic Inclinometer Calibrator
CXJ-2 High Precision Automatic Inclinometer Calibrator
CXJ-2 High Precision Automatic Inclinometer Calibrator
CXJ-2 High Precision Automatic Inclinometer Calibrator
CXJ-2 High Precision Automatic Inclinometer Calibrator
CXJ-2 High Precision Automatic Inclinometer Calibrator
CXJ-2 High Precision Automatic Inclinometer Calibrator
CXJ-2 High Precision Automatic Inclinometer Calibrator
Specifications
Brand Name :
RUYA
Model Number :
CXJ-2
Certification :
ISO 9001
Place of Origin :
China
MOQ :
1 pc
Price :
negotiable
Payment Terms :
T/T
Supply Ability :
1-10 piece， 4-6 weeks
Delivery Time :
20-30 working days
Packaging Details :
Wooden box
Table Diameter :
Ф195mm
Load :
≤15Kg
Table Runout :
0.02mm
Table Flatness :
0.02mm
Description

CXJ-2 High-precision Automatic Inclinometer Calibrator

Product Description

The automatic inclinometer calibrator is a device used to calibrate inclinometers. It can automatically complete the calibration of the inclinometer and improve the accuracy and efficiency of the calibration.

In practical applications, automatic inclinometer calibrator can be used to calibrate various types of inclinometers, such as fixed inclinometers, sliding inclinometers, etc. It can help users ensure the measurement precision and accuracy of inclinometers and improve the quality and reliability of engineering measurements.

Product parameters

Specification

1

Table Diameter

Ф195mm

2

Table Flatness

0.02mm

3

Table Runout

0.02mm

4

Load Capability

≤15Kg

5

Rotary Accuracy Of Axis

±3″

6

Positioning Error Of Angular Position

±3″

7

Positioning Repeatability Of Angular Position

±1.5″

8

Adjustable Range Of Perpendicularity

±15°

9

Dimensions

Control System:950×500×1160 mm

Body:500×500×950 mm

10

Measurement Software

Compiled in accordance with JJF1550-2015 inclinometer calibration specifications, automatic indexing of the calibration table can be realized, and all detection functions are normal.

CXJ-2 High Precision Automatic Inclinometer Calibrator

CXJ-2 High Precision Automatic Inclinometer Calibrator
