SM090-4VI Refrigeration Scroll Compressor 7.5HP SM090S4VC For Air Conditioning
SM090-4VI Refrigeration Scroll Compressor 7.5HP SM090S4VC For Air Conditioning
SM090-4VI Refrigeration Scroll Compressor 7.5HP SM090S4VC For Air Conditioning
SM090-4VI Refrigeration Scroll Compressor 7.5HP SM090S4VC For Air Conditioning
Specifications
Brand Name :
Danfoss
Model Number :
SM090S4VC
Certification :
CE UL
Place of Origin :
China
MOQ :
1PCS
Price :
discussed
Payment Terms :
T/T, Western Union
Supply Ability :
500PCS
Delivery Time :
1-5 Days
Packaging Details :
wooden packaging
Color :
Blue
Apllication :
refrigeration
Type :
refrigeration compressor
Product name :
SM090-6VI
warranty :
1 year
Horse power :
7.5HP
Net weight :
65KG
Voltage :
230/3/50
Refrigerant :
R22
Product name: :
Scroll compressor
Segment usage :
Air conditioning
Description
SM090-4VI Refrigeration Scroll Compressor 7.5HP SM090S4VC For Air Conditioning
Product Overview
High-performance SM090-4VI scroll compressor designed for air conditioning applications, featuring 7.5HP capacity and robust construction.
Key Specifications
Gross Weight70.53 kg
Net Weight65 kg
EAN5702424540593
Approval StandardCE
Brand TechniqueScroll compressor
Capacity ControlFixed speed
Compressor Power Supply230/3/50 V/Ph/Hz
Model NumberSM090S6VC
RefrigerantR22
Nominal Cooling Capacity at 50Hz19.7 kW
Technical Details
Diameter254 mm
Total Height508 mm
Discharge Connection Size3/4 in
Suction Connection Size1 1/8 in
IP Protection ClassIP54 (with cable gland)
Motor ProtectionInternal overload protector
Rotational Speed at 50Hz2900 rpm
Oil TypeMineral
Oil Charge3.25 L
Refrigerant Charge [Max]8.5 kg
Electrical Specifications
Phase3
RLA21.4 A
LRA165 A
MCC30 A
Maximum Operating Current27 A
Winding Resistance0.5 Ohm
Pressure Ratings
High Side Max Pressure30.2 bar
Low Side Max Pressure25 bar
Factory HP33 bar
Factory LP25 bar
