Specifications
Brand Name :
ZL
Model Number :
ZL-4001
Certification :
CE,ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
2800-3500
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
50 sets / month
Delivery Time :
7-14 work days
Packaging Details :
Metal Detector in Food Processing Industries, Industrial Metal Detector Conveyor is packaged within wooden case.
Product name :
Metal Detector in Food Processing Industries, Industrial Metal Detector Conveyor
FE Sensitivity :
0.6-3.0-customize
Non-Fe Sensitivity :
1.2-3.5-customize
SUS Sensitivity :
1.5-4.0-customize
Speed :
10-30 m/min optional (default constant speed)
Certificate :
CE
Storage Function :
99 products, 990,000 data
Optional :
Rejection of duplicates, push rods, and air blows
Description
Industrial Metal Detector Conveyor for Food Processing
Advanced metal detection system designed specifically for food processing industries, featuring high-sensitivity detection and robust construction for reliable foreign object detection.
Key Features
  • Full digital DSP programming design with dual-channel signal detection for high sensitivity and anti-interference capability
  • 4.3-inch touch screen interface for easy operation
  • Digital chip processing with automatic learning for optimal detection phase
  • Storage capacity for 99 products and 990,000 data points
  • Automatic product effect learning for sugar-containing and salt-containing foods
  • 304 stainless steel construction with laser cutting and wire drawing process
  • Food-grade white PVC or PU belt with Japanese bearings and Mitsubishi synchronous belt
  • Alarm modes: buzzer alarm with automatic shutdown and rewind function
  • Super shockproof capability to prevent false alarms from collision
Technical Specifications
Parameter ZL-4001B Specifications
Detection Width 400mm (Other widths customizable)
Detection Height Options 100mm, 120mm, 150mm, 200mm, 250mm, 300mm, 350mm, 400mm
FE Sensitivity (Ф mm) ≥0.6 to ≥3.0 (depending on detection height)
Non-FE Sensitivity (Ф mm) ≥1.2 to ≥3.5 (depending on detection height)
SUS Sensitivity (Ф mm) ≥1.5 to ≥4.0 (depending on detection height)
Alarm Method Automatic shutdown with 12V buzzer alarm and rewind
Machine Size 1330*720*1000mm (L*W*H) - customizable
Belt Material Food grade PVC or PU Belt (food contact safe)
Speed 10-30 m/min (default constant speed)
Machine Weight Approximately 200-250KG
Power 220V 50Hz, 120W (customizable)
Load Capacity Within 20KG (customizable)
Belt Height from Ground 700mm (other heights customizable)
Storage Function 99 products, 990,000 data points
Optional Features
• 7-inch touch screen with USB interface for data export
• Rejection systems: duplicates, push rods, and air blows
Sensitivity parameters are approximate values from empty machine testing. Actual test parameters may vary depending on the test object.
