Specifications
Brand Name :
ZL
Model Number :
ZL-6016
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
60 Sets
Delivery Time :
5-8 work days
Packaging Details :
ISO 20653 IEC60529 IEC 6059 Rain Test Chamber With IPX3 IPX4 IPX5 IPX6 is packaged within wooden case.
Product name :
ISO 20653 IEC60529 IEC 6059 Rain Test Chamber With IPX3 IPX4 IPX5 IPX6
Specification Model :
ZL-6016
Inner Box Size :
W600xD600xH 600 mm (Customized inner box size available)
Outer Box Size :
W1100xD800xH1800 mm
Test Bench Speed :
1-5rpm Adjustable
Diameter of Water Spray Ring :
400mm
Spray Hole Diameter :
0.8mm
Spray Hole Distance :
50mm spacing
Description

ISO 20653 IEC60529 IEC 6059 Rain Test Chamber With IPX3 IPX4 IPX5 IPX6

Water Resistance Rain test Chamber Equipment Rain Water Spray Waterproof Testing Machine Price is according to IEC60529, IEC 60598, GB2423.37-89 (Test L:dust test methods), GB 4208-93 protective casing grade (IP code), GB/T 4942.2-93(protective casing grade of low-voltage apparatus), GB 7000.1-1996, GB 7001-1986(protective casing grade of lamps), DIN40050 and IP5K0.

Equipment Parameters
Specification Model ZL-6016
Inner Box Size W600xD600xH 600 mm (Customized inner box size available)
Outer Box Size W1100xD800xH1800 mm
Inner Box Material 304 mirror finish stainless steel
Outer Box Material 304 brushed stainless steel
Depending on Window Size 400x400 mm
Test Bench Speed 1-5rpm Adjustable
Turntable Load 25KG

Diameter of

Water Spray Ring

 400mm
Spray Hole Diameter 0.8 mm
Spray Hole Distance 50mm spacing
Water Spray Pressure Adjustable water flow as specified
Pendulum Diameter 16 mm
Test Time 1-999 minutes
Pendulum Angle ±45°, ±60°, ±90°, ±180° (adjustable)
Using the Power Supply 220V 1.5KW
