Specifications
Model Number :
ZL-4025B
Packaging Details :
wooden case packaging
MOQ :
1 set
Delivery Time :
7-15 work days
Adjustable outlet height :
370 mm (max. +200 mm)
Brand Name :
ZL
Payment Terms :
T/T,D/P,D/A,L/C
Discharge pipe diameter :
40 mm
Inlet height :
680 mm (max. +200 mm)
Price :
UDS2300-3500
Detection Sensitivity :
Stainless Steel (SUS): Φ0.4 mm
Supply Ability :
60 Sets
Name :
Metal Detectors for Capsules& Tablets
Certification :
CE,ISO
Housing Material :
SUS304 mirrorfinish stainless steel
Place of Origin :
Guangdong, China
Description
Metal Detectors for Capsules & Tablets
Product Overview

Metal Separator is specially designed for pharmaceutical and health-care industries requiring ultra-high detection accuracy. Adopting German-based technology, it delivers ultra-high sensitivity and stable reliable performance, and can rapidly reject products contaminated with metal foreign bodies.

Scope of Application

Suitable for detecting metal contaminants in pills, tablets, capsules, granule instant drinks and fine powders.

Product Features
  • Human-oriented intelligent operating system with 7-inch high-definition touch screen for intuitive and convenient operation
  • Unique high precision detection of tiny metal fragments with maximum throughput of approximately 15,000 pieces per minute
  • Capable of handling various pharmaceutical products with compact frame design to save installation space
  • Constructed of SUS304 mirror-finish stainless steel with food-grade material for reject device and product-passing tubes
  • Product-parameter memory function stores detection parameters for up to 100 products
  • One-click auto-setup function for fast product change-over and minimized setup time
  • Manual adjustment for frame height and tilt angle with lockable casters for easy movement
  • Modular components for quick maintenance and anti-vibration whole-machine design
  • Access permission setting with independent passwords for administrator and operator accounts
  • Multi-language selection (Chinese, English, Japanese, etc.) with custom languages available
  • Date-filtered production log query and reject-count display for detailed analysis
  • Wide-range power supply 110-240V, 50-60Hz, no external transformer required
Technical Parameters
Item Specification
Discharge pipe diameter 40 mm
Detection Sensitivity Ferrous (Fe): Φ0.2 mm
Non-Ferrous (NON Fe): Φ0.5 mm
Stainless Steel (SUS): Φ0.4 mm
Housing Material SUS304 mirror-finish stainless steel
Inlet height 680 mm (max. +200 mm)
Adjustable outlet height 370 mm (max. +200 mm)
Power Supply 110V-240V, 50-60Hz
Alarm & Reject Mode Audible-visual alarm, flap reject
Adjustable angle 30° ~ 40°
