450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
Specifications
Place of Origin :
Shandong, China
Brand Name :
HUALONG
Certification :
CE
Packaging Details :
standard packing
Supply Ability :
10 Set/Sets per Month
Price :
$25,000.00/sets >=1 sets
Model Number :
XK-450
MOQ :
1 set
Delivery Time :
30 days
Core Components :
PLC, Engine, Bearing, Gearbox, Motor, bearbox
Cooling Mode :
water cooling
Power (kW) :
55kw
Applicable Industries :
Rubber plastic industry
Machine type :
Rubber mixing mill machine
Model type :
XK-450
Bush type :
Bearing
Gearbox :
Hard gear reducer
Lubrication :
Automatic grease
Roller hardness :
Chilled cast iron hardness HS 72
Description
Hot Sale Rubber Mixing Mill Rubber Mixing Mill Open Type XK-450
Type
XK-400
XK-450
XK-560
XK-550B
XK-660
Working diameter of rolls (mm)
400
450
560/510
550
660
Working Length of rolls (mm)
1000
1200
1530
1500
2130
Front roll surface speed (m/min)
18.65
24.26
27.72
27.94
28.6
Friction ratio
1:1.27
1:1.27
1:1.2
1:1.22
1:1.24
Max. nip (mm)
10
15
15
15
15
Capacity per batch (kg)
18-35
25-50
35-50
50-60
165
Motor power (KW)
37
55
90
110
245
Size (L*W*H) (mm)
4350*1850*1785
5200*2380*1840
5845*2284*1978
5878*2475*2045
7455*3662*2080
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
Safe emergency stop device
▲two emergency stop buttons
▲ overhead emergency stop rope
▲ kick emergency stop switch
Non-operating side
▲ two emergency stop buttons
▲ overhead safety pull cord
▲ Kick emergency stop switch
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
Plus one plate of plane thrust bearing,each mill has 12 plates of bearing,saving energy by 10-15% and reducing grease usage by 20-25%
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
Open mixing mill machine the speed ratio gear made of 42CrMo alloy steel after forging and heat treatment
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
Rubber mixing mill machine frame with tempering treatment
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
Rubber mixing mill bearing seat with tempering heat treatment
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
Each bearing has two disc double row cylindrical roller bearings
Equipment application and operation requirements
1. Main application: mixing mill is mainly used for rubber compound warming, mixing &sheeting, as well as raw rubber plasticating, mixing &sheeting.
2. Operation requirements
A. running environment: altitude＜1000m,
temperature: 5℃-40℃, max. relative humidity 95%
B. Power supply: AC380V, 50Hz, 3-phase
C. Cooling water pressure: 2-0.4Mpa
Cooling water temperature: ﹤25℃±3℃
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
QINGDAO SHENGHUALONG RUBBER MACHINERY CO.,LTD 450mm 55Kw Rubber Mixing Mill Machine For Mixing And SheetingMore than 30 years history of manufacturing experience. 6-8 years foreign sales experience staff, more efficiency and professional.

Technical advantages

Service timely, promise to give solution within 12 hours, guarantee customer trouble free.
For rubber machine, we mainly produce rubber kneader series, rubber mixing mill series, rubber extruder and strainer series, rubber powder line, rubber reclaim sheet line, rubber tube line, rubber mat line, tire making line and so on, we can make more than 200 series rubber machines, including environment protect machines, we also can make rubber machine according to customers requirement. Till now, HANGSEN have exported to more than forty counties, including USA, Greece, Spain, Poland, France, Italy, Algeria, Egypt, India, Russia, Argentina, Vietnam, Brazil, Indonesia, Thailand and so on. Our company uses exquisite and professional technology to serve all customers and is widely praised and appreciated by customers. We provide customers with high-quality and timely service.
450mm 55Kw Rubber Mixing Mill Machine For Mixing And Sheeting
