RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery
Specifications
Rated Capacity :
400Ah
Rated Voltage :
51.2V
Output Voltage Range :
43.2V ~ 58.4V
Rated Energy :
20.48kWh
Description

Key Features

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

Built-in wheels for easy mobility

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

400Ah capacity

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

Touch screen LCD display

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

Overcharge & over-discharge protection

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

WiFi & Bluetooth connectivity

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

6,000+ cycle life with 80% DOD

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

Simple installation

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

Compatible with most inverters

Technical Specifications

Rated Voltage51.2V
Rated Capacity400Ah
Rated Energy16.08kWh / 20.48kWh
Output Voltage Range43.2V ~ 58.4V
Charging Voltage57.6V ~ 58.4V
Cut-off Voltage43.2V
Max Charging Current200A (400Ah)
Recommended Charging Current100A (400Ah)
Max Discharging Current200A (400Ah)
Efficiency>98%
Dimensions 314Ah (L×W×H)825 × 415 × 235 mm
Dimensions 400Ah (L×W×H)880 × 540 × 235 mm
Weight 314Ah≈120 kg
Weight 400Ah≈160 kg
IP RatingIP20
Cycle Life>6,000 (0.2C, @25℃, 80% DOD)
Design Life>5 years
Charging Temperature0℃ ~ 55℃
Discharging Temperature-20℃ ~ 60℃
Storage Temperature-10℃ ~ 30℃
Humidity5% ~ 95% RH
Operating ModeTouch Screen

Application Scenarios

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

Villa

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

Private Home

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

Manor

RPES-W2 51.2V400Ah 20.48kWh Wheeled Residential LiFePO4 Battery

Small Farm

Certifications

CEIEC62619UN38.3RoHS
