RPES-WM4 25.6V 100Ah/200Ah 2.56 / 5.12kWh
Wall-Mounted Residential LiFePO4 Battery

Specifications

Rated Energy :

2.56kWh / 5.12kWh

Rated Voltage :

25.6V

Rated Capacity :

100Ah / 200Ah

Output Voltage Range :

21.6V ~ 29.2V

Description

RPES WM4 is a compact wall-mounted energy storage system available in
100Ah (2.56kWh) and 200Ah (5.12kWh) configurations. Its sleek and modern
design seamlessly integrates into any space, with a touch screen display for
intuitive power level monitoring.

Key Features

Sleek wall-mounted design

100Ah/200Ah dual capacity options

Touch screen LCD display

Clear power level indicators

6,000+ cycle life with 80% DOD

Lightweight and compact

Flexible installation options

Compatible with various inverters

Technical Specifications

Rated Voltage25.6V

Rated Capacity100Ah / 200Ah

Rated Energy2.56kWh / 5.12kWh

Output Voltage Range21.6V ~ 29.2V

Charging Voltage28.8V ~ 29.2V

Cut-off Voltage21.6V

Max Charging Current100A

Recommended Charging Current50A

Max Discharging Current100A

Efficiency>98%

Dimensions 100Ah (L×W×H)435 × 385 × 145 mm

Dimensions 200Ah (L×W×H)650 × 385 × 145 mm

Weight 100Ah≈25 kg

Weight 200Ah≈48 kg

Humidity5% ~ 95% RH

Cycle Life>6,000 (0.2C, @25℃, 80% DOD)

Design Life>10 years

Charging Temperature0℃ ~ 55℃

Discharging Temperature-20℃ ~ 60℃

Storage Temperature-10℃ ~ 30℃

Operating ModeTouch Screen

Application Scenarios

Villa

Private Home

Manor

Small Farm

Certifications

CEIEC62619UN38.3RoHS
