Specifications
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
PLC
Place of Origin :
Hebei, China
Brand Name :
HuaYU
warranty :
1 Year
productivity :
100L/Hour
weight (kg) :
800
Processing Type :
filtration
Dimension(L*W*H) :
1500mm/750mm/1920mm
Power :
10KW
Voltage :
380V
Description

Industrial & Commercial High-Efficiency UF Ultrafiltration System Water Treatment Machinery for Pure Water Solutions

Product Description

Technical Features of Ultrafiltration Equipment

  1. High-Efficiency Separation and Purification

    • High Recovery Rate: Ensures excellent product quality with efficient material separation, purification, and high-multiple concentration.
    • Compliance with Hygiene Standards: Uses sanitary-grade pipes and valves, meeting GMP or FDA production regulations to maintain a clean and hygienic production environment.
    • Compact and Efficient: Advanced process design with a high degree of integration, small footprint, easy operation and maintenance, reducing labor intensity.

  2. Gentle Processing, Retaining Bioactivity

    • No Phase Change: The entire process occurs without phase changes, ensuring no adverse effects on material composition and maintaining product purity and stability.
    • Low-Temperature Protection: Operates at ambient temperature, making it particularly suitable for heat-sensitive substances, preventing thermal damage to bioactive compounds while preserving essential nutrients.

  3. Energy-Saving and Cost-Effective

    • Low Energy Consumption: Compared to traditional processes, it features lower energy consumption, shorter production cycles, and significantly reduced operating costs, enhancing economic benefits for enterprises.

  4. Eco-Friendly and Versatile

    • No Need for Chemical Additives: Simple operation without additional chemical reagents, ensuring product safety.
    • Mild Experimental Conditions: No temperature or pH fluctuations, preventing denaturation, inactivation, or autolysis of biomolecules, making it ideal for desalination, dehydration, and concentration of biomolecules.
Detailed Images

Industrial & Commercial High-Efficiency UF Ultrafiltration System Water Treatment Machinery for Pure Water Solutions

Our Advantages

Industrial & Commercial High-Efficiency UF Ultrafiltration System Water Treatment Machinery for Pure Water Solutions

Working principle

Industrial & Commercial High-Efficiency UF Ultrafiltration System Water Treatment Machinery for Pure Water Solutions

Product Parameters

Parameters HYHJ-UF-0.5T HYHJ-UF-1T HYHJ-UF-2T
Machine Size(L*W*H) 1500mm/700mm/1700mm 1500mm/750mm/1920mm 1600mm/900mm/1920mm
Control mode Fully automatic operation Fully automatic operation Fully automatic operation
Device power AC/380V/50HZ AC/380V/50HZ AC/380V/50HZ
Raw water pump Q=2m³/H H=30m Q=2m³/H H=30m Q=3m³/H H=30m
UF booster pump Q=1m³/H H=30m Q=1.5m³/H H=30m Q=3m³/H H=30m
Quartz sand filter φ250×1400mm φ300×1650mm φ400×1650mm
Activated carbon filter φ250×1400mm φ300×1650mm φ400×1650mm
Precision filters 5 cores 10 inches 5 cores 20 inches 5 cores 40 inches
Precision filter element 10''5μm 20''5μm 40''5μm
Backwash manifold Solenoid manifold Solenoid manifold Solenoid manifold
Ultrafiltration membrane model Hollow fiber + PVDF Hollow fiber + PVDF Hollow fiber + PVDF

Applications

Industrial & Commercial High-Efficiency UF Ultrafiltration System Water Treatment Machinery for Pure Water Solutions
