Specifications
video outgoing-inspection :
Provided
machinery test report :
Provided
core components :
PLC
Place of Origin :
Hebei, China
Brand Name :
HuaYU
warranty :
1 Year
productivity :
100L/Hour
weight (kg) :
800
Processing Type :
filtration
Dimension(L*W*H) :
1500mm/750mm/1920mm
Power :
10KW
Voltage :
380V
Description

Water Filtration System Drinking Water Treatment Equipment UF Ultrafiltration System

Product Description

Technical Features of Ultrafiltration Equipment

  1. High-Efficiency Separation and Purification

    • High Recovery Rate: Ensures excellent product quality with efficient material separation, purification, and high-multiple concentration.
    • Compliance with Hygiene Standards: Uses sanitary-grade pipes and valves, meeting GMP or FDA production regulations to maintain a clean and hygienic production environment.
    • Compact and Efficient: Advanced process design with a high degree of integration, small footprint, easy operation and maintenance, reducing labor intensity.

  2. Gentle Processing, Retaining Bioactivity

    • No Phase Change: The entire process occurs without phase changes, ensuring no adverse effects on material composition and maintaining product purity and stability.
    • Low-Temperature Protection: Operates at ambient temperature, making it particularly suitable for heat-sensitive substances, preventing thermal damage to bioactive compounds while preserving essential nutrients.

  3. Energy-Saving and Cost-Effective

    • Low Energy Consumption: Compared to traditional processes, it features lower energy consumption, shorter production cycles, and significantly reduced operating costs, enhancing economic benefits for enterprises.

  4. Eco-Friendly and Versatile

    • No Need for Chemical Additives: Simple operation without additional chemical reagents, ensuring product safety.
    • Mild Experimental Conditions: No temperature or pH fluctuations, preventing denaturation, inactivation, or autolysis of biomolecules, making it ideal for desalination, dehydration, and concentration of biomolecules.
Detailed Images

Water Filtration System Drinking Water Treatment Equipment UF Ultrafiltration System

Our Advantages

Water Filtration System Drinking Water Treatment Equipment UF Ultrafiltration System

Working principle

Water Filtration System Drinking Water Treatment Equipment UF Ultrafiltration System

Product Parameters

Parameters HYHJ-UF-0.5T HYHJ-UF-1T HYHJ-UF-2T
Machine Size(L*W*H) 1500mm/700mm/1700mm 1500mm/750mm/1920mm 1600mm/900mm/1920mm
Control mode Fully automatic operation Fully automatic operation Fully automatic operation
Device power AC/380V/50HZ AC/380V/50HZ AC/380V/50HZ
Raw water pump Q=2m³/H H=30m Q=2m³/H H=30m Q=3m³/H H=30m
UF booster pump Q=1m³/H H=30m Q=1.5m³/H H=30m Q=3m³/H H=30m
Quartz sand filter φ250×1400mm φ300×1650mm φ400×1650mm
Activated carbon filter φ250×1400mm φ300×1650mm φ400×1650mm
Precision filters 5 cores 10 inches 5 cores 20 inches 5 cores 40 inches
Precision filter element 10''5μm 20''5μm 40''5μm
Backwash manifold Solenoid manifold Solenoid manifold Solenoid manifold
Ultrafiltration membrane model Hollow fiber + PVDF Hollow fiber + PVDF Hollow fiber + PVDF

Applications

Water Filtration System Drinking Water Treatment Equipment UF Ultrafiltration System
