Specifications
Brand Name :
B-Tohin
Model Number :
BKW6005
Certification :
ISO9001/ ISO14001/CE
Place of Origin :
China
MOQ :
1 set
Price :
USD 3170- USD 4280
Payment Terms :
L/C, T/T
Supply Ability :
200 sets per month
Delivery Time :
20 work days
Packaging Details :
export wooden case
Name :
Three lobe Roots Blower
Material :
Iron
Color :
Customed
Air Capacity :
3.62m3/Min-11.15m3/Min
Motor Power :
1.5KW
Cooling Type :
Water
Outlet size :
DN80(3")
Blower RPM :
850-1800
Voltage :
380V/400V/415V/440V/Customed
Frequency :
50HZ/60HZ
Application :
Waste water treatment
Installation type: :
horizontal or vertical
Description

Areation Water Cooling Roots Air Blower BKW6005 At 60-100 Kpa Long Life

About BKW
BKW seires Roots Blower inherits most components from BK series, it adopts water cooling in bearing cover, which can reduce the temperature of bearing when working and prolong the longevity, also it has a larger pressure capability.
Roots blowers are used to aerate raw sewage and industrial organic waste. The aeration drives the digestion of the waste by microorganisms. Roots blowers are also used for grit tank cleaning, filter flushing, backwashing and the recovery of gases. Oil-free roots blowers are used for deep cell aeration.

Specifications:

Model BKW6005
Air capacity 4.04m3/Min-10.27m3/Min
Discharge differential pressure 60-100KPA
Rotary speed 850rpm-1800rpm
Motor type 5.5-7.5/11-15/18.5-22KW
380/400/415/440V, 3PHASES, 50/60HZ
Installation type Standard: horizontal type.
Vertical type available for your option
N.W. of blower without motor 275 kg
Packing size Approx. 1.50*1.05*1.75m (length*width*height)
Features 1. Helical type timing gears for smooth operation
2. Compact, flexibility in installation gives users more choices.
3. Integral structure of impeller and shaft
4. Adopt imported oil seals made from fluoric rubber with bettr wear resistance and high-temperature resistance.
5. Low noise, low vibration and energy consumption.


Parameters

Type Port Dia Speed Inlet airflow(m3/min)and shaft power(KW)at different conditions Cooling Water
60kpa 70kpa 80kpa 90kpa 100kpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW L/min
BKW6005 80(3'') 850 3.54 7.13 3.34 8.04 5
1000 4.60 8.39 4.40 9.45 4.22 10.73 4.04 12.00
1150 5.67 9.65 5.46 10.87 5.29 12.33 5.10 13.80
1250 6.38 10.49 6.17 11.82 5.99 13.41 5.81 15.00 5.65 16.59
1400 7.44 11.74 7.23 13.24 7.06 15.02 6.87 16.80 6.72 18.58
1500 8.15 12.58 7.94 14.18 7.76 16.09 7.58 18.00 7.42 19.90
1650 9.21 13.84 9.00 15.60 8.83 17.7 8.64 19.79 8.49 21.89
1800 10.27 15.10 10.07 17.02 9.89 19.31 9.71 21.59 9.55 23.88

Working Principle

Roots blower is a cubage blower, and it discharges a fixed amount of air in proportion to its rotation speed. Every rotation, there is two lobes to finish three times absorbing and dischargeing air. Compared with two lobes blower, it is of less air pulses, smaller load change, higher strength, lower noise and vibration.

Two paraller shafts have three lobes each, all the lobes keep small clearance with each other and housing inside. Every lobes rotatiomn, a certain air will be absorbed at inlet and transfeered form the housing inside surface to blower's diacharge port.

Two shafts will be turned by the timing gears, no any touching between lobes, so it can be turned at high speed without any lubrication inside. It has the following chaaracteristics: simply configuration; running smoothly;good performance stabilization. It has been widely applied in various industries.

Sewage Treatment Three Lobe Roots Blower Water Cooling Long Life

Sewage Treatment Three Lobe Roots Blower Water Cooling Long Life

Structure

Sewage Treatment Three Lobe Roots Blower Water Cooling Long Life


Application

Sewage Treatment Three Lobe Roots Blower Water Cooling Long Life

Sewage Treatment Three Lobe Roots Blower Water Cooling Long Life
