Vacuum 50KPA To 70KPA DN65 2.5”Negative Pressure Rotary Lobe Blower
Vacuum 50KPA To 70KPA DN65 2.5”Negative Pressure Rotary Lobe Blower
Vacuum 50KPA To 70KPA DN65 2.5”Negative Pressure Rotary Lobe Blower
Vacuum 50KPA To 70KPA DN65 2.5”Negative Pressure Rotary Lobe Blower
Specifications
Brand Name :
BK
Model Number :
BV65H
Certification :
ISO9001/ISO14001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
80 SETS per month
Delivery Time :
5 to 20 working days, depends on order amount and specification
Packaging Details :
Export standard wooden caseAbout BKW BKW series roots blower inherits the design of BK series. It adopts water cooling in bearing cover, which can lower the temperature of bearing so as to prolong the bearing’s service life and enable higher pressure appli
Type :
vacuum sauction, roots type
Air capacity :
2.07-4.06m3/min
Discharge differential pressure :
-50KPA ~ -70KPA
Motor power :
3-4/5.5-7.5/11KW
Discharge bore :
DN65(2.5")
Cooling type :
Air
Driven type :
motor driven, connected by belt and pulley
Speed :
1500-2200 Rpm
Weight :
176 kg
Description

Vacuum 50KPA to vacuum 70KPA Roots negative pressure blower vacuum Pump DN65 lobe rotary type blower


About BV65H Vacuum Blower

BV65H vacuum blower is a kind of displacement Roots type air pump. It can reach -70KPA vacuum pump. It is widely used for vacuum air conveying and if featured of stable performance and excellent volumetric efficiency.


Specifications

Model

BV65H

Air capacity

2.07-4.06m3/min

Discharge differential pressure

-50 ~ -70KPA

Rotary speed

1500-2200rpm

Motor type

3-4/5.5-7.5/11KW

380/400/415/440V, 3PHASES, 50/60HZ

Installation type

Standard: vertical type

N.W. of blower without motor

176kg


Parameter sheet

Model Speed Inlet capacity (m3/min)and shaft power (KW)
-0.5kgf/cm² -0.55kgf/cm² -0.6kgf/cm² -0.65kgf/cm² -0.7kgf/cm²
-5000mmH2O -5500mmH2O -6000mmH2O -6500mmH2O -7000mmH2O
-0.05Mpa -0.055Mpa -0.06Mpa -0.065Mpa -0.07Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
BV65H 1500 2.3 4.26 2.23 4.49 2.16 4.72 2.07 4.96
Port Dia: DN65(2.5") 1700 2.79 4.83 2.72 5.09 2.66 5.35 2.57 5.62 2.48 5.88
1900 3.3 5.4 3.23 5.69 3.16 5.98 3.06 6.28 2.97 6.57
2100 3.74 5.89 3.67 6.21 3.59 6.53 3.5 6.85 3.4 7.17
2200 4.06 6.25 3.98 6.59 3.91 6.93 3.82 7.27 3.72 7.6

Assembling drawing of blower package

Vacuum 50KPA To 70KPA DN65 2.5”Negative Pressure Rotary Lobe Blower

Dimension size

BV-H Outline Dimension Sheet Unit:mm

Type
Port Dia
Motor power(kw)		 A B B1 C D E F G J K M N 0 P W Q T U n-M16×h
Weight
(kg)
BV65H (2.5") 3～4 760 500 0 130 83 815 190 115 103 165.5 242 238 300 350 143 25 1490 370 4-M16×300 176
5.5～7.5 790 550 120 330 380
11～15 840 600 120 288 380 430
Standard accessories include:intake, outlet muffler, negative pressure gauge,base,belt cover,vacuum relief valve,triangular belt.
The weight above are for standard accessories only,motor excluded.


Standard supply of scope

1. blower main body

2. vacuum safety valve

3. inlet silencer

4. outlet silencer

5. public base (with belt cover)

6. rubber flexible joint and shock pad

7. blower pulley

8. pressure gauge

9. belt

10. bolts and nuts and other connection parts

11. motor
