Specifications
Brand Name :
BK
Model Number :
BV150H
Certification :
ISO9001/ISO14001
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
80 SETS per month
Delivery Time :
5 to 20 working days, depends on order amount and specification
Packaging Details :
Export standard wooden caseAbout BKW BKW series roots blower inherits the design of BK series. It adopts water cooling in bearing cover, which can lower the temperature of bearing so as to prolong the bearing’s service life and enable higher pressure appli
Type :
vacuum sauction, roots type
Air capacity :
18.25-32.25m3/min
Discharge differential pressure :
-50KPA ~-70KPA
Motor power :
18.5-22/30/37-45/55KW
Discharge bore :
DN150(6")
Cooling type :
Air
Driven type :
motor driven, connected by belt and pulley
Description

DN150 Roots type vacuum pump negative pressure blower,18.25-32.25m3/min,-50KPA to -70KPA, 30-55KW

About BV150H Vacuum Blower

BV150H vacuum blower is a kind of displacement Roots type air pump. It can reach -70KPA vacuum pump. It is widely used for vacuum air conveying and if featured of stable performance and excellent volumetric efficiency.


Specifications

Model

BV150H

Air capacity

18.25-32.25m3/min

Discharge differential pressure

-50~ -70KPA

Rotary speed

1330-2080rpm

Motor type

18.5-22/30/37-45/55KW

380/400/415/440V, 3PHASES, 50/60HZ

Installation type

Standard: vertical type

N.W. of blower without motor

545kg


Parameter sheet

Model Speed Inlet capacity (m3/min)and shaft power (KW)
-0.5kgf/cm² -0.55kgf/cm² -0.6kgf/cm² -0.65kgf/cm² -0.7kgf/cm²
-5000mmH2O -5500mmH2O -6000mmH2O -6500mmH2O -7000mmH2O
-0.05Mpa -0.055Mpa -0.06Mpa -0.065Mpa -0.07Mpa
rpm m3/min KW m3/min KW m3/min KW m3/min KW m3/min KW
BV150H 1330 19.06 23.02 18.83 24.46 18.6 25.9 18.25 27.34
Port Dia: DN150(6") 1420 20.64 24.58 20.41 26.11 20.18 27.65 19.81 29.18
1580 23.46 27.35 23.22 29.06 22.99 30.76 22.59 32.47
1670 25.04 28.9 24.8 30.71 24.57 32.52 24.16 34.32 23.75 36.13
1870 28.55 32.37 28.31 34.39 28.07 36.41 27.63 38.43 27.19 40.46
1980 30.49 34.27 30.25 36.41 30.00 38.55 29.54 40.69 29.08 42.84
2080 32.25 36 32.00 38.25 31.76 40.50 31.28 42.75 30.81 45

Assembling drawing of blower package

DN150 (6“ ) 27.19m3/min 45kw -70KPA Roots Blower Vacuum Pump

Dimension size

BV-H Outline Dimension Sheet Unit:mm

Type
Port Dia
Motor power(kw)		 A B B1 C D E F G J K M N 0 P W Q T U n-M16×h
Weight
(kg)
BV150H (6") 18.5～22 1040 800 400 120 117 1000 280 180 163 232 430.5 254.5 505 555 301 25 2007 547 6-M16×400 545
30 1070 135
37～45 1130 900 450 115 258 370.5 620 676 305 28 573 573
55 1180 140
Standard accessories include:intake, outlet muffler, negative pressure gauge,base,belt cover,vacuum relief valve,triangular belt.
The weight above are for standard accessories only,motor excluded.


Standard supply of scope

1. blower main body

2. vacuum safety valve

3. inlet silencer

4. outlet silencer

5. public base (with belt cover)

6. rubber flexible joint and shock pad

7. blower pulley

8. pressure gauge

9. belt

10. bolts and nuts and other connection parts

11. motor
