High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
Specifications
Package Size :
600.00cm * 130.00cm * 140.00cm
Package Gross Weight :
7000.000kg
Model NO. :
Ridge tile machine
Certification :
CE, SGS
Customized :
Customized
Transmission Method :
Electric
Transmission Mode :
1inch Chain Drive
Transport Package :
Plastic Film & Steel Wire Fixed
Tile Type :
Colored Steel
Condition :
New
Usage :
Roof
Electronic Control System :
PLC
Place of Origin :
CHINA
Brand Name :
HENGFU
MOQ :
1 Piece
Packaging Details :
Plastic Film & Steel Wire Fixed
Delivery Time :
45Days
Payment Terms :
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Description
High Speed 460 Ridge Tile Machine Automatic Metal Roof Cap Cold Roll Forming Equipment
Dongguang Hengfu Roll Forming Machine Co., Ltd. presents its high-performance Ridge Cap Roll Forming Machine, engineered for reliable, efficient production of precision-formed ridge caps for modern metal roofing systems. Designed for continuous operation and long service life, this machine combines robust construction with advanced control technology to meet demanding manufacturing requirements worldwide.
The machine features a heavy-duty 350H steel frame that provides exceptional rigidity and stability during high-speed forming, preventing vibration and ensuring dimensional accuracy. Equipped with precision-arranged roll forming stations, it gradually shapes galvanized steel, aluminum, prepainted coils, and aluzinc sheets into uniform, clean-finish ridge caps without surface damage.
Powered by a reliable electric drive system and intuitive PLC touchscreen control, this machine offers fully automated operation from coil feeding to final cutting, reducing labor requirements and improving production efficiency. Operators can easily adjust forming speed, length parameters, and production counts via the user-friendly interface.
Technical Specifications
Model NO460 Ridge tiles
Machine frame350H steel frame
Motor4kW or 5.5kW oil pump motor
Wall panel thickness14mm wall panels
Type of DrivenChain drive
Number of rolling mill sets16-row molding
Spindle diameter70 shafts
Shear power5.5kW servo drive
Wheels45# wheels
UsageRoof
Specification6000mmx1300mmx1400mm
OriginCangzhou, Hebei
Warranty1 year
Product Gallery
High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing High Speed 460 Ridge Tile Machine with PLC Control and 350H Steel Frame for Durable Metal Roofing
Frequently Asked Questions
How can issues such as skewed or off-center sheet feeding be resolved?
The equipment is equipped with a hydraulic alignment system or a manually adjustable feed guide mechanism, allowing for easy correction.
Can the machine produce curved or irregularly shaped panels?
Yes, it can be customized with arching and bending mechanisms to enable the forming of curved roofing tiles.
Is there a leveling device at the material inlet?
It is equipped with a set of leveling rollers to ensure flat feeding and prevent waves or distortion in the sheet material.
Is the electrical system susceptible to moisture damage?
The electrical cabinet features a dust-proof and moisture-resistant design, allowing it to operate normally even within a simple outdoor shelter.
Can you provide semi-automatic or fully automatic receiving tables?
Yes, optional configurations include pneumatic receiving, hydraulic receiving, and automatic stackers.
