Specifications
Brand Name :
HUA QUN
Model Number :
HQTK
Certification :
ISO
Place of Origin :
Guangdong China
MOQ :
1 Set
Price :
Pending
Payment Terms :
L/C,T/T
Supply Ability :
5 set per day
Delivery Time :
5-8 working days
Packaging Details :
Packed by wooden box
Name :
Thermoplastic Preheater
Total weight of machine :
350-850kg
Hydraulic tank volume :
40 litres
Application :
Road marking
Outer dimensions(L*W*H) :
depend on model
Capacity of Melting Coating :
300kg/500kg/800kg
Stirring Method :
Stirring Method
Description

Thermoplastic Road Marking Paint Kneader Hydraulic Preheater for Road Marking Materials


A thermoplastic road marking kneader is a specialized piece of equipment used in the application of thermoplastic road markings. It's essentially a heating and mixing device that prepares the thermoplastic material for application onto road surfaces. This equipment ensures the material reaches the correct temperature and consistency for optimal adhesion and durability of the road markings.


No. Model HQ1 HQ2 HQ3
1 Outer dimensions 1620*1620*1400mm 1400*1400*1350mm 750mm*1700mm*1370mm
2 Empty weight 850kg 550kg 350kg
3 Thickness of boiler bottom 8mm 8mm 8mm
Diameter of boiler 700mm 550mm 600mm
Height of boiler 550mm 550mm 550mm
Capacity of paint 400kg*2 250kg*2 300kg/400kg
4 Agitator rotating speed 0-80r/min 0-80r/min 0-80r/min
5 Thickness of outer frame(stainless steel ) 2mm 2mm 2mm
6 Capacity of hydraulic oil tank 60L 60L 60L
7 Diesel engine power 12KW (16HP) 7 HP 7 HP
8 Engine start method Electrical(12V), Manual Electrical(12V), Manual Electrical(12V), Manual


Key Features:


Hydraulic Drive:
Many kneaders use hydraulic systems for efficient and controlled mixing.
Dual Tank System:
Some models, like the twin-tank kneader, have two separate tanks to allow for continuous operation, with one tank heating while the other is being emptied.
Adjustable Speed:
Step-less speed regulation allows for precise control over the mixing process.
High-Efficiency Heating System:
Kneaders often incorporate specialized heating systems, like stainless steel or high carbon steel pots, and high-efficiency burners, to ensure rapid and efficient heating of the material.
Safety Features:
Kneaders are designed with safety features like emergency stop buttons and safety guards to protect operators.
User-Friendly Design:
Many models feature intuitive controls, ergonomic handles, and convenient level indicators for ease of use.
