Energy Saving Hydraulic Double Pre Heater Kneader with Large Capacity for Thermoplastic Powder Melting
Energy Saving Hydraulic Double Pre Heater Kneader with Large Capacity for Thermoplastic Powder Melting
Energy Saving Hydraulic Double Pre Heater Kneader with Large Capacity for Thermoplastic Powder Melting
Energy Saving Hydraulic Double Pre Heater Kneader with Large Capacity for Thermoplastic Powder Melting
Specifications
Payment Terms :
L/C,T/T
Price :
Pending
Type :
Mixing and kneading equipment
Supply Ability :
50 set per day
Net Weight :
700kg/1000kg/1200kg
Service :
OEM
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 Set
Capacity :
Varies by model, typically 10-500 liters
Delivery Time :
5-8 working days
Packaging Details :
Packed by wooden box
Usage :
For traffic safety purposes
Outer dimensions :
1400*1400*1350mm, 1520*1520*1400mm, 1620*1620*1400mm
Operatingtemperature :
Up to 300°C
Dimensions :
Depends on model, typically customized
Brand Name :
HUA QUN
Model Number :
CK800/CK1000/CK1200
Application :
Thermoplastic processing, compounding, mixing
Length :
Customized
Productname :
Thermoplastic Kneader
Material :
Stainless steel or alloy steel
Description
Energy Saving Thermoplastic Kneader with Advanced Hydraulic Double Pre-Heater

The Hydraulic Double-cylinder Thermoplastic Kneader is a key machine for thermoplastic marking construction, featuring hydraulic drive and multi-way reversing valve control for positive and reverse rotation. This design significantly accelerates melting speed, making it ideal for construction sites requiring rapid material processing such as freeways, state highways, and provincial highways.

With increasing liquefied petroleum gas costs and resource shortages, kneader efficiency has become critically important. The mixing uniformity and melting speed of coating materials directly impact both road marking quality and construction costs. Our thermoplastic kneaders complete road marking construction in shorter timeframes while maintaining superior quality standards.

Technical Specifications
Model HQ-YA HQ-YB HQ-YC
Outer dimensions (L*W*H) 1400*1400*1350mm 1520*1520*1400mm 1620*1620*1400mm
Capacity (melted paint) 250kg*2 (Total 500kg) 300kg*2 (Total 600kg) 400kg*2 (Total 800kg)
Cover plate material Stainless plate (rust-resistant) Stainless plate (rust-resistant) Stainless plate (rust-resistant)
Total weight of machine 650kg 780kg 850kg
Diesel engine power 5.6kw/7HP 12kw/16HP 12kw/16HP
Key Features
  • Function: Melts thermoplastic material to reach optimal marking temperature (180-220℃)
  • Stirring speed: 30-80r/min adjustable range
  • Engine start method: Electrical (12V) or Manual operation
  • Used fuel: LPG (Liquefied Petroleum Gas)
  • 30% higher efficiency compared to similar products
  • Faster melting speed with more even mixing
  • Hydraulic drive with multi-way reversing valve control
