3 Ton Industrial Forklift Truck , Diesel Engine Forklift With 3000MM Max Lifting Height
3 Ton Industrial Forklift Truck , Diesel Engine Forklift With 3000MM Max Lifting Height
3 Ton Industrial Forklift Truck , Diesel Engine Forklift With 3000MM Max Lifting Height
3 Ton Industrial Forklift Truck , Diesel Engine Forklift With 3000MM Max Lifting Height
3 Ton Industrial Forklift Truck , Diesel Engine Forklift With 3000MM Max Lifting Height
3 Ton Industrial Forklift Truck , Diesel Engine Forklift With 3000MM Max Lifting Height
Specifications
Brand Name :
KUDAT
Model Number :
CPQYD30
Certification :
ISO / CE
Place of Origin :
CHINA
MOQ :
1 unit
Price :
negotiation
Payment Terms :
L/C at sight, T/T or western Union
Supply Ability :
1500 units per month
Delivery Time :
15 working days after received L/C or your deposit
Packaging Details :
Naked packing in container
Power type :
Diesel
Rated capacity :
3000 kg
Load center :
500 mm
Mast Lifting height :
3000 mm
Max. grade ability :
20%
Free lift height :
240 mm
Fork size(L*W*T) :
1070×125×45 mm
Min Turning Radius :
2230 mm
Max Driving speeds :
17.5 / 20 km/h
Total weight :
3600 kg
Description

3 Ton LPG Forklift Truck With 3000MM Max Lifting Height for Material Moving

Specifications:

Model

Unit

CPQYD30

Power type

　

Gasoline/LPG

Rated capacity

kg

3000

Load center

mm

500

Max Lifting height

mm

3000

Free lift height

mm

160

Fork size(L*W*T)

mm

1070×125×45

Tilting Angles(Front/Rear)

deg

6°/12°

Front overhang

mm

479

Exterior Size

Length without fork

mm

2682

Overall width

mm

1225

Mast drop

mm

2065

Max. lift

mm

4262

Front-wheel Overhead

mm

2090

Min Turning Radius

mm

2400

Min. intersecting aisle

mm

2380

Speeds

Max Driving speeds

km/h

18/19

Lifting speeds

mm/s

440/480

Lowering speeds

mm/s

450/500

Max. grade ability

%

20

Total weight

kg

4270

Tires

Front

　

28×9-15-12PR

Rear

　

6.50-10-10PR

Wheelbase

mm

1700

Tread

Front

mm

1000

Rear

mm

970

Min. ground clearance

mm

135

Engine

Model

　

Chinese GQ-4Y Gasoline engine

Rated output

kw/rpm

34/2500

Rated torque

N.m/rpm

142/1800

No. of cylinder

　

4

Displacement

L

2.237

Fuel tank capacity

L

60


Description:
About LPG forklift trucks: Kudat brand LPG forklift is available with a loading capacity ranging from 2 tons to 4 tons. Kudat LPG forklift utilizes world famous engine GM to provide moderate power, high reliability, low fuel consumption and low noise. These types sale well in America area and operate well in many applications.
Advantage of gas forklift: An innovative operator compartment design offers easy driver access, excellent all-round visibility and conveniently located controls. These LPG forklifts adopt Germany technology, which greatly enhances the reliability and meets the Europe Standard.
Main Features:

  • Chine wanfeng or Nissan gasoline engine.
  • 3M 2Stage duplex mast.
  • High-quality with lower price.
  • load capacity 3000kg.

















Product tags

2.5 ton diesel forklift

,

4.5 ton forklift

,

3.5 ton forklift
