8.1mm Steel Cord ST/S3150 800mm Fire Retardant Conveyor Belt
8.1mm Steel Cord ST/S3150 800mm Fire Retardant Conveyor Belt
Specifications
Brand Name :
TSKY
Model Number :
ST/S3150
Certification :
SGS, ISO, BV, CE
Place of Origin :
Qingdao, China
MOQ :
100m
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000m per day
Delivery Time :
7-15 working days after confirmed order
Packaging Details :
Export standard container: 20GP or 40GP, 40HC
Name :
ST/S3150 Fire Resistant Steel Cord Conveyor Belt Fire Retardant Conveyor Belt
Max. Diameter of Steel Cord :
8.1mm
Top Rubber Cover Thickness :
8.0mm
Bottom Rubber Cover Thickness :
8.0mm
Belt Width :
800mm-2200mm
No. Of Steel Cord :
50-141
Warranty :
12 Months
Description

ST/S3150 Fire Resistant Steel Cord Conveyor Belt Fire Retardant Conveyor Belt

Steel cord conveyor belt is composed of single wire rope of the same diameter arranged according to certain spacing, twisting around and white, up and down repeatedly in different properties of the plastic core, plastic cover, after vulcanization. If you have special need, you can add transverse laceration resistant fabric mesh, wire mesh or buried coil, prevent tape horizontal tear or covered with special performance of rubber cover, and then made into different performance of steel cord conveyor belt.

Features of ST/S3150 Fire Resistant Steel Cord Conveyor Belt Fire Retardant Conveyor Belt

The ST/S3150 fire resistant steel cord conveyor belt is also called ST/S3150 fire retardant steel cord conveyor belt.

The ST/S3150 fire resistant steel cord conveyor belt fire retardant conveyor belt uses galvanize steel cord with high strength and low elongation. The top rubber cover and bottom rubber cover are made of high quality rubber material with fire resistant (fire retardant) & anti-static.

Under constant tension, the ST/S3150 fire resistant steel cord conveyor belt fire retardant conveyor belt can be used to transport materials in the fire resistant (fire-retardant) and static electricity-conducting environment of coal mines by pasting and vulcanizing.

TheST/S3150 fire resistant steel cord conveyor belt fire retardant conveyor belt is suitable for use in underground mines.

The ST/S3150 fire resistant steel cord conveyor belt fire retardant conveyor belt is fire-resistant (fire-retardant), anti-static, high tensile strength, long service life, good trough formation and good flexibility resistance.

Therefore, the ST/S3150 fire resistant steel cord conveyor belt fire retardant conveyor belt is suitable for long-distance, large-span, large conveying capacity and high speed transportation project.

Technical Parameter List of ST/S3150 Fire Resistant Steel Cord Conveyor Belt Fire Retardant Conveyor Belt

(Execution Standard: MT668-2008)
Model ST/S630 ST/S800 ST/S1000 ST/S1250 ST/S1600 ST/S2000 ST/S2500 ST/S2800 ST/S3150 ST/S3550
Max. Diameter of Steel Cord (mm) 3.0 3.5 4.0 4.5 5.0 6.0 7.2 7.5 8.1 8.6
Top Rubber Cover Thickness (mm) 5.0 5.0 6.0 6.0 6.0 8.0 8.0 8.0 8.0 8.0
Bottom Rubber Cover Thickness (mm) 5.0 5.0 6.0 6.0 6.0 8.0 8.0 8.0 8.0 8.0
Belt Width (mm) No. Of Steel Cord
800 75 75 63 63 63 63 50 50 50 50
1000 95 95 79 79 79 79 64 64 64 64
1200 113 113 94 94 94 94 76 76 76 77
1400 133 133 111 111 111 111 89 89 89 90
1600 151 151 126 126 126 126 101 101 101 10-4
1800 - 171 143 143 143 143 114 114 114 114
2000 - - 159 159 159 159 128 128 128 128
2200 - - - - - 176 141 141 141 141
