1-1840860-2 1000 Base-T 2x6 RJ45 Multi Connector with LED
1-1840860-2 1000 Base-T 2x6 RJ45 Multi Connector with LED
1-1840860-2 1000 Base-T 2x6 RJ45 Multi Connector with LED
1-1840860-2 1000 Base-T 2x6 RJ45 Multi Connector with LED
Specifications
Brand Name :
LINK-PP
Model Number :
1-1840860-2
Certification :
ROHS,Reach
Place of Origin :
China
MOQ :
50pcs
Price :
$0.09-$2.3
Payment Terms :
TT, NET30/60/90 Days
Supply Ability :
6.5million-PCS/Month
Delivery Time :
Ships within 1-2 weeks
Packaging Details :
Tape and Reel (1 Reel = 350pcs)
Number of Channels/Ports :
2x6
Mounting Style :
Through Hole Mount
PoE Rating :
Non-PoE
Data Rate :
Gigabit
Size :
41.20 x 87.01 x 25.50mm
Isolation Voltage :
2250VDC
Description

Key Features of 1-1840860-2 10/100/1000 Base-T MagJack:

  • Gigabit Ethernet Support (10/100/1000BASE-T)
  • Built-in Magnetics for signal isolation and EMI reduction
  • Compact 2x6 Stacked Design saves PCB space
  • Wave Solder Compatible – 260°C peak, 10 sec
  • Enhanced EMI Shielding with integrated tabs
  • Standards Compliant: IEEE 802.3af, RoHS, UL, REACH
  • Operating Temp: 0°C to +70°C
  • Ideal for IP cameras, VoIP phones, WAPs

Electrical Specifications @25℃:

Items/Part Number 1-1840860-2 MagJack
Turns Ratio 1:1 All four pairs
Media side inductance 350uH min @100KHz, 0.1VRMS, 8mA DC bias
Insertion Loss - 1.1dB max from 1.0MHz to 100MHz
Return Loss

- 18dB min from 1.0MHz to 40MHz;
- 12-20LOG(f/80)dB min from 40.1MHz to 100MHz
Crosstalk Attenuation - 35dB min from 1.0MHz to 40MHz;
- 33-20LOG(f/50)dB min from 40.1MHz to 100MHz
Isolation Voltage 2250VDC (max) for 60 seconds with a rise time of 500V/sec
Operating Temperature 0°C - +70°C
Common Mode Rejection Ratio (CMRR) - 30dB min from 1.0MHz to 100MHz

2x6 RJ45 with Magnetics Application:

• Blade servers or cards
• Network Interface cards
• Laptop computers
• Storage systems
• Mezzanine cards

1-1840860-2 Schematic:

1-1840860-2 1000 Base-T 2x6 RJ45 Multi Connector with LED

1-1840860-2 Datasheet:

1-1840860-2 1000 Base-T 2x6 RJ45 Multi Connector with LED
