XFGIB100APOL-COMBO1-1S 1000Base-T Magjack LPJG4810NNL Made in China
XFGIB100APOL-COMBO1-1S 1000Base-T Magjack LPJG4810NNL Made in China
Specifications
Brand Name :
LINK-PP
Model Number :
XFGIB100APOL-COMBO1-1S
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
China
MOQ :
50/500/1000
Price :
Supportive
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
4600K.PCS/Month
Delivery Time :
Stock
Packaging Details :
50pcs/tray,1200pcs/carton
part Number :
XFGIB100APOL-COMBO1-1S
Specification :
LPJG4810NNL
Cross&Datasheet :
LPJG4810NNL
Apllication :
10/100 or 1000Base-T(x)
Original Munafactuer :
LINK-PP
Mail Customer :
Ti, Intel, Cisco, Samsung, Fluke, Arduino ,Hp,Jabil,Flextronics
Description

XFGIB100APOL-COMBO1-1S 1000Base-T Magjack LPJG4810NNL Flexible PCB Assembly

Competitor Cross Reference

Part Number

Manufacturer

Part Number

 Manufacturer Description

XFGIB100APOL-COMBO1-1S

LPJG4810NNL

 LINK-PP

XFGIB100APOL-COMBO1-1S 1000Base-T Magjack LPJG4810NNL Flexible PCB Assembly
Series Connector Type Applications Mounting Type
Connectors, Interconnects LINK-PP Female Rj45

10/100

or 1000 Mbps

 Thru-Hole(SMT for Single Port)
Orientation Termination LED Color Shielding

90° Angle (Right) or

180°(Vertical)

 Solder With Or Without (Un)Shielded,EMI-Finger(With Or Wi)

Features

  • RJ-45 connector integrated with Filter
  • Size same as RJ-45 connector to save PCB board space
  • Reduce EMI radiation, Improve EMI performance
  • High performance for maximum EMI suppression.
  • ISO9001,SGS,UL,CE,REACH
  • Embedded mini PCI express Cellular modemfrom SierraWireless
  • Reduce EMI radiation, Improve EMI performance
  • Certified on all major carrier networks,attractive for network interface cards(NICS)Single port,
  • Multi-port and Stackable configurations (Thru-hole/ SMT)

  • Reduces the number of components to be placed on the board

  • Frees up board space and offers signal protection

  • Noise reduction in the system

  • Improved reliability and optimal system performance

  • Benefits of having shorter signal paths and the reliability gains from systems containing fewer components

  • Helps manufacturers reach their goals of cost reduction

Related Part

TGR01-3406V6LF TIC-L040-11 J20-0014 13F-64NW2
TGR04-3406V6LF TIC-L041-11 J20-0017 13F-64GYDNW2
TGR07-3206V6LF TIC-L044-14 J20-0019 13F-64ND2
TGR23-3206V6LF TIC-L047-11 J20-0114NL 13F-64GYD2
TG01-0406N1RL TIC-L048-11 JX20-0114NL 13F-64GGD2
TG20-S001N1RL TIC-L050-14 J20-0015 13F-61ND2
TG57-0406N1RL TIC-L051-11 J20-0115NL 13F-64AND2
TG74-0406N1RL TIC-L052-11 JX20-0115NL 13F-64AGGD2
TG01-0456N1RL PTC11XX-09D J20-0016 13F-62ANW2
TG57-0456N1RL PH162479G J20-0116NL 13F-62AGYDNW2
TG74-0456N1RL PTC1111-90 JX20-0116NL 13F-62AGGDNW2
TG01-0406NSRL PTC1111-54L1VG JK0-0114NL 13F-62AND2
TD01-0406NERL PTC11XX-01 JK0-0187NL 13F-62AGYD2
TG04-0406NSRL 20PMT04B JK0-0193NL 13F-62AGGD2
TD04-0406NERL 13F-61JGYDPH2NL JK0-0116NL 13F-62ADGD2
TG07-0206NSRL PTC1111-54L1VG JK0-0136NL 13F-62CGYD2
TD07-0206NERL PTC1111-54L1VG JK0-0117NL 13F-60CND2
TG23-0206NSRL PTC111101G JK0-0144BNL 13F-60END2
TD23-0206NERL PTC111112SS JC0-3022NL 13F-60VGYD2
TG01-0456NSRL PTC111101 JKM-0001NL 13F-61FND2
TD01-0456NERL PTC111189L1G JKM-0004NL 13F-66YGDNW2

XFGIB100APOL-COMBO1-1S 1000Base-T Magjack LPJG4810NNL Made in China

XFGIB100APOL-COMBO1-1S 1000Base-T Magjack LPJG4810NNL Made in China

Why Choose LINK-PP

Quality

World’s Leader supplier of Integrated RJ45 Connector and Discrete Magnetic Transformers.

Original materials suppliers are selected and appointed by Tyco Electronic ,and then put into production at the standard of Tyco Electronic .

  • Manufactured under strict controls.
  • ISO 9001:2008
  • UL Certification
  • Reach Cetitifaction
  • RoHS compliance
  • OEM Of TE(Tyco) For 9 Years
  • Active Environmental policy
  • Every module tested (not just batch tested)
Main Customers

Texas Instruments INTEL SAMSUNG FLUKE EKF HUAWEI IBM CISCO
FLEXTRONICS JABIL Foxconn CANON Arduino -- --- ---

LINK-PP RJ45 Designed for BeagleBone Black of Texas Instruments
