JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED
JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED
JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED
JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED
JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED
JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED
JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED
JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED
JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED
JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED
Specifications
Brand Name :
LINK-PP
Model Number :
JXD0-4005NL
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
China
MOQ :
50/500/1000
Price :
Supportive
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
4200K-PCS/Month
Delivery Time :
Stock
Packaging Details :
50pcs/tray,1200pcs/carton
Part Number :
JXD0-4005NL
Speed :
10/100 Base-T
OperatingTemperature :
-40℃~85℃
LED :
Green/Yellow led
Files :
PDF/3D/ISG/Stp/Step/Datasheet/Touchstone Format/S-parameters
Lifecycle :
More than 10 Years
Description
JXD0-4005NL 1x4 port 8pin led connector with shrapnel rj45 female connector rj45 modular jack Network Connector

Package Bulk
Part Status Active
Connector Type RJ45
Applications 10/100 Base-T, AutoMDIX
Mounting Type Through Hole
Orientation 90℃ Angle (Right)
Termination Solder
Height Above Board 0.526" (13.36mm)
LED Color Green - Yellow
Number of Cores per Jack 4
Shielding Shielded, EMI Finger
Features Board Guide
Tab Direction Down
Contact Material Phosphor Brass
Contact Finish Gold
Operating Temperature -40℃ ~ 85℃
Contact Finish Thickness 6.00uin (0.152uim)
Shield Material Brass
Housing Material Thermoplastic
Number of Ports 4
Number of Rows 1

JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED

JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LEDJXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED

JXD0-4005NL RJ45 Female Connector 1x4 Port 8pin With LED

JXD0-4005NL CONN,RJ45,1X4,100D,1:1,TY NPB
CONTACT MATING AREA PLATING GOLD 30 U''
LATCH DOWN
LED OPTION GREEN & YELLOW
NUMBER OF PORTS 1X4
PACKAGE THT
PACKAGE HEIGHT MM 13.500
PACKAGE LENGTH MM 21.350
PACKAGE WIDTH MM 59.050
PCB MOUNT ANGLE SIDE ENTRY
POE RATING NON-POE
ROHS COMPLIANT YES-RoHS-6
SPEED 100BASE-TX
TEMPERATURE -40 TO +85
TURNS RATIO 1:1
Packaging Tray
Part Status Active
Connector Type RJ45
Number of Ports 4
Number of Rows 1
Applications 10/100 Base-TX, AutoMDIX
Mounting Type Through Hole
Orientation 90° Angle (Right)
Termination Solder
Height Above Board 0.531" (13.49mm)
LED Color Green - Yellow
Number of Cores per Jack 4
Shielding Shielded, EMI Finger
Features Board Lock
Tab Direction Down
Contact Material Copper Alloy
Contact Finish Gold
Operating Temperature -40°C ~ 85°C
Contact Finish Thickness 30.0µin (0.76µm)
Shield Material Brass
Housing Material Thermoplastic
https://www.micro-semiconductor.com/datasheet/da-JXD0-4005NL.pdf
RoHs Status:Lead free / RoHS Compliant
After-sales
1. Each product from LINK-PP has been given a warranty period of 365 days. During this period, we could provide free technical maintenance if there are any problems about our products.
2. If you find quality problems about our products after receiving them, you could test them and apply for unconditional refund if it can be proved.
3. If the products are defective or they don't working, you can return to us within 1 YEAR, all transportation and customs charges of the goods are borne by us.
