RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL
RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL
RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL
RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL
RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL
RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL
RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL
RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL
RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL
RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL
Specifications
Brand Name :
LINK-PP
Model Number :
RM3-KA-0005
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
China
MOQ :
50/500/1000/25K
Price :
$0.05-$1.28
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
4200K-PCS/Month
Delivery Time :
Stock
Packaging Details :
50pcs/tray,1200pcs/carton
part Number :
RM3-KA-0005
Mass Production :
LPJ17003-8AENL
Original Munafactuer :
LINK-PP
Application :
1000Base-T
Termination :
Solder
LEDs :
GREEN/YELLOW&GREEN
Description
RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL

Category
Category RJ45 connector -PCB Socket 8P8C (DIP)
Filter 1000 Base-T
Entry Angle 90° Angle
LED Green/Yellow&Green
Color - Resin Black
Electrical
Current - Maximum per Contact 1.50A
Voltage - Maximum 125V
Contact Resistance 30 mΩ Max
Insulation Resistance 500 MΩ Min
Withstanding Voltage 1000V AC r.m.s
Temperature Range operating 0ºC~+70ºC
Material and Plating
Material-Metal Phosphor Bronze
Material - Plating Mating Gold
Material - Plating Termination Gold
Material - Resin PBT UL94V-0

RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NLRM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NLRM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL

RM3-KA-0005 1000 Base-T 2x1 Port RJ45 Mmagnetic Jack LPJG17549A8NL

•Free Samples. •Delivery Time 1-2 Weeks.

LINK-PP Electronic SFPRJ45 Connector and LAN Transformer 10+ years of Manufacturing Experience.

Factory

•We have over 1000 workers.

•The area of ZhuSun is 60,000 square meters.

•Huizhou LINK-PP Electronics Co.,Ltd have owns 3 factory in sichuan,hubei,Zhejiang.

Quality

•Lean production management.

•100% Tested (Not Just Batch Tested).

•Quality Guarantee:5 Years.

Certification

•ISO 9001:2008,

•ROHS CE FCC Compliance

•Active Environmental Policy.

Have R&D dept

•OEM Service Offered,Design Service Offered.

•Engineer Can Design Products As You Need,Developer Tooling As Customer Require.

Price And Service

•Than PULSE TE HALO BEL Wurth Amphenol MOLXE BOTHHAND ABRACON FOXCONN And HANRUN More Competitive Price And Delivery.

,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian

EMS Application

Central Controller, Embedded Ethernet controller, Active Optical Network, Fingerprint Access Control, Industrial embedded communication controller, Intelligent monitoring equipment ,smarthome control systems,passive optical access networks, NETWORKED VIDEO INTEGRATION DEVICES, STORAGE SYSTEMS FOR IP VIDEO SURVEILLANCE,IP CAMERA INSTALLATION TOOLS,External Board Series...
