JG2014A61R Magnetic RJ45 Jack 10/100/1000Mbps Female Connectors LINK-PP
JG2014A61R Magnetic RJ45 Jack 10/100/1000Mbps Female Connectors LINK-PP
Specifications
Brand Name :
LINK-PP
Model Number :
JG2014A61R
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
China
MOQ :
50/500/1000
Price :
Supportive
Payment Terms :
TT,NET30/60/90 Days
Supply Ability :
4600K.PCS/Month
Delivery Time :
Stock
Packaging Details :
50pcs/tray,1200pcs/carton
Specification :
JG2014A61R
Part No :
JG2014A61R
Ethernet :
Gigabit Lan
Turn Ratio :
1:1
Mounting :
90 Degree Shield
Samples :
Available
Description

JG2014A61R Magnetic RJ45 Jack 10/100/1000Mbps Female Connectors LINK-PP

  • Ethernet rj-45 Port compatible With 10/100/1000mbps
  • LINK-PP JG2014A61R Rj45 Gigabit Connectors
  • 1xRj45 Ethernet Port Latch-up Model

Electrical Specifications @25℃
1.Impedance: 100 ohms
2.OCL: 350uH Min
@100KHz,0.1Vrms,8mADC BIAS
3.Turns Ratio: 1∶1
4.Insertion Loss:
0.5-100MHz:-1.1dB Max
5.Return Loss(dB Min):
0.5-40MHz:-18
40.1-100MHz:-12-20LOG(f/50)
6.Crosstalk(dB Min):
0.5-40MHz:-35
40.1-100MHz:-33-20LOG(f/50)
7.Common Mode Rejection Ratio:
0.5-100MHz:-30 dB Min
8.Isolation Voltage: 1500Vrms Min
9.Operating Temperature: 0℃～70℃.

JG2014A61R Magnetic RJ45 Jack 10/100/1000Mbps Female Connectors LINK-PP
JG2014A61R Magnetic RJ45 Jack 10/100/1000Mbps Female Connectors LINK-PP JG2014A61R Magnetic RJ45 Jack 10/100/1000Mbps Female Connectors LINK-PP
