Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Specifications
Model NO. :
AEH-20-40
Certification :
GMA, QS, FDA, ISO, CE
Automation :
Automatic
Screw :
Multi-Screw
Treatment :
Pyrolysis
Incinerator Size(mm) :
1200*1300*1800
Treatment Quantity(Kg/Batch) :
20-40
Incinerator Volume(M2) :
3.0
Power Consumption(Kw/H) :
2-4
Oil Consumption(L/H) :
3-8
Physical Weighing(T) :
2.2-5.5
Transport Package :
Wooden Box
Specification :
5t/day
Trademark :
Aoerheng
Origin :
China
HS Code :
8417809090
Production Capacity :
50000 Sets / Year
Description
Flue gas treatment qualified incinerator for medical waste and domestic garbage

1.product characteristic:

Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
It has a wide range of treatment, which can handle most of the garbage
(household garbage, plastic garbage, wood, paper, cotton and other combustible garbage), and the final product is ceramic ash
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
The product can be reused, and the burnt domestic waste put into it will be turned into ceramic ash after treatment (if metal and other non-disposable waste is mixed in, it will remain in its original state and be eliminated).
Ceramic dust can be used for construction, insulation materials, and for agricultural fertilizers.
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Low operating costs. The pyrolysis carbonization furnace draws on the theory that low-temperature magnetization technology uses magnetic motion to promote carbonization and pyrolysis, and has researched and invented a technology that can carbonize and pyrolyze garbage without using electricity, gas, oil and other high-consumption energy sources.
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
Environmentally friendly garbage disposal. The carbonization pyrolysis furnace is equipped with deodorization and smoke exhaust treatment equipment. It avoids the discharge of pollutants such as dioxins and ammonia oxides caused by garbage incineration locks. The gas emissions are odorless and harmless, while reducing carbon dioxide emissions.

2.Introduction to grate:

Grate Grate support Bellows Housing Furnace wall Driving device
The grate is arranged horizontally,which is divided into drying section,incineration section1 and incineration section 2 from front to back



Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage

3.product parameters:


Serial number
 Specification and model Main equipment size Processing capacity
(kg/batch)		 incinerator volume
(m2)		 Power consumption
(kw/h)		 oil wear
(l/h)		 Equipmentweight
(t)
1 AEHA-25 1000*900*1700 25 2.5 2 3 1.15
2 AEHA-20-40 1200*1300*1800 20-40 3.0 2-4 3-8 2.2-5.5
3 AEHA-20-60 1700*1500*2100 20-60 5.0 2-5 3-10 4.5-7.8
4 AEHA-50-120 2200*2000*2500 50-120 10.0 3-12 4-15 5.0-11.5
5 AEHA-100-300 3000*3500*2900 100-300 13.0 10-30 10-40 15-25
6 AEHA-400-500 3000*3700*3200 400-500 17.0 40-50 50-60 30-45

4.Tail gas reference standard:
The pollution control standard for hazardous waste incineration (GB18484-2001) of the State Environmental Protection Administration was implemented on January 1, 2001. The allowable concentration of pollutants discharged from flue gas is as follows:

number contaminants Maximum allowable emission concentration limit under different incinerator capacity(mg/m3)

≤300(Kg/h) 300~2500(Kg/h ≥2500(Kg/h)
1 Smoke blackness Ringerman level1
2 Smoke 100 80 65
3 Carbon monoxide 100 80 80
4 Sulfur dioxide 400 300 200
5 Hydrogen fluoride 9.0 7.0 5.0
6 Hydrogen chloride 100 70 60
7 Nitrogen oxide 0.1
8 Mercury and its compounds 500
9 Cadmium and its compounds 0.1
10 Arsenic nickel and their compounds 1.0
11 Lead and its compounds 1.0
12 Chromium,tin,antimony,copper,manganese,and their compounds 4.0
13 Dioxins 0.5TEQ ng/m3



5.Our transportation:
Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic GarbageFlue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage
6.Our factory:

AEHA series harmless incinerator is a domestic and international harmless incineration treatment equipment developed by introducing Japanese

harmless incinerator technology, organizing technical public relations, sublating the advantages and disadvantages of similar equipment at home

and abroad. The equipment has the characteristics of small volume, incineration, reasonable process, technology and high degree of

harmlessness. It is an ideal waste treatment equipment for all kinds of hospitals, hotels, stations, sanitation stations, laboratories and farms.

Flue Gas Treatment Qualified Incinerator for Medical Waste and Domestic Garbage AOERHENG company covers an area of 20000 square meters. The company adopts modern enterprise management concept. seiko manufacturing. forge ahead. the product quality is superior to the domestic and foreign counterparts products.

Company technical force is abundant. the craft is advanced. Complete range of articles. in strict accordance with ISO9001 standards. organization.design. production.sales and management.

Company sets scientific research and development. engineering design. Installation. debugging.Production services for the integration of domestic comprehensive backbone enterprises.

Products with free-pollution disposal equipment. Garbage disposal equipment. High concentration wastewater treatment equipment. Organic fertilizer production equipment. Air treatment equipment.

Sludge treatment equipment. Automobile processing equipment such as environmental protection equipment . And can design according to customer demand.

Customization of all kinds of efficient and practical equipment and production line.

7.Our services:

pre-sale

1. Selection of equipment model.

2. Design and manufacture products according to the special requirements of customers.

3. The manufacturer shall send engineers and technicians to inspect the site free of charge.

sale

1. Product acceptance.

2. Assist the customer to formulate the construction scheme.

after-sales

1. Free guidance on equipment installation and commissioning

2. Train technical personnel for customers

3. On site training for operators
