TL720D-CAN2.0A/B High-Precision MEMS Gyroscope Sensor with Azimuth Output for AGV Applications and IP67 Protection
TL720D-CAN2.0A/B High-Precision MEMS Gyroscope Sensor with Azimuth Output for AGV Applications and IP67 Protection
TL720D-CAN2.0A/B High-Precision MEMS Gyroscope Sensor with Azimuth Output for AGV Applications and IP67 Protection
TL720D-CAN2.0A/B High-Precision MEMS Gyroscope Sensor with Azimuth Output for AGV Applications and IP67 Protection
TL720D-CAN2.0A/B High-Precision MEMS Gyroscope Sensor with Azimuth Output for AGV Applications and IP67 Protection
TL720D-CAN2.0A/B High-Precision MEMS Gyroscope Sensor with Azimuth Output for AGV Applications and IP67 Protection
Specifications
Brand Name :
RION
Model Number :
TL720D-CAN2.0A/B
Place of Origin :
Shenzhen
MOQ :
1
Price :
$60/Pieces
Delivery Time :
5-8 work days
Heading measure axis :
Z axis heading angle (±180)°
Bandwidth :
>100Hz
Nonlinear :
0.1% of FS
Startup time :
AGV application: 5 ~ 6s/AGM application: 1.5s
ShockInput voltage :
9~36VDC / 5VDC(optional )
Working current :
30mA(12V)
Working temp :
-40℃ ~ +80℃
Protection grade :
IP67
Description
TL720D-CAN2.0A/B High-Precision Gyroscope Azimuth Output for AGV
The TL720D is a high-precision gyroscope developed using the latest MEMS inertial measurement platform. It provides real-time horizontal azimuth angle output by processing gyroscope angular rate, forward axis body acceleration, and implementing dynamic attitude algorithms. The integrated inertial navigation algorithm utilizes multi-model data fusion to effectively minimize short-term gyroscope drift.
Designed specifically for automated agricultural machinery, precision work applications, AGV systems, and forklift automatic navigation vehicles, this product enhances operational efficiency and represents an essential component in next-generation automated precision agriculture and industrial control systems.
Key Features
• Azimuth angle output
• Strong vibration resistance
• Light weight design
• Long life with strong stability
• Cost-effective solution
• DC 9-36V power supply
• Compact & lightweight
• CAN2.0A/CAN2.0B output options
• All solid state construction
Technical Specifications
Parameter Specification
Heading measure axis Z axis heading angle (±180)°
Bandwidth >100Hz
Position accuracy <2mm/m (angle conversion)
Nonlinear 0.1% of FS
Accelerometer range ±4g
Acceleration resolution 0.001g
Acceleration accuracy 5mg
Bias instability (allan) 0.05mg
Speed random walk coefficient (allan) 0.015m/s/sqrt(h)
Bias stability (10s average) 0.15mg
Max Gyro Range ±250°/s
Angle random walk coefficient (allan) 0.30°/sqrt(h)
Bias stability (10s smooth) 10°/h
Startup time AGV: 5-6s | AGM: 1.5s
Input voltage 9-36VDC / 5VDC (optional)
Working current 30mA (12V)
Working temperature -40℃ to +80℃
Storage temperature -40℃ to +85℃
Vibration 5g-10g
Impact 200g pk, 2ms, ½ sine
Working life 10 years
Output rate 1Hz-100Hz (configurable)
Output signal CAN2.0A / CAN2.0B (optional)
MTBF ≥98,000 hours
Insulation resistance ≥100 MΩ
Shockproof 100g@11ms / 3 Axial Direction (Half Sinusoid)
Anti-vibration 10grms / 10-1000Hz
Protection grade IP67
Weight ≤135g (including 1 meter standard cable)
Applications

★ Automated Agricultural Machinery

★ Precision Agriculture

★ Forklift Truck

★ Cultivator

★ AGV


TL720D-CAN2.0A/B High-Precision MEMS Gyroscope Sensor with Azimuth Output for AGV Applications and IP67 Protection

TL720D-CAN2.0A/B High-Precision MEMS Gyroscope Sensor with Azimuth Output for AGV Applications and IP67 Protection

TL720D-CAN2.0A/B High-Precision MEMS Gyroscope Sensor with Azimuth Output for AGV Applications and IP67 Protection
