Automatic Rigid Box Corner Pasting Machine Suction Board Type Feeding Grey Board
Automatic Rigid Box Corner Pasting Machine Suction Board Type Feeding Grey Board
Automatic Rigid Box Corner Pasting Machine Suction Board Type Feeding Grey Board
Automatic Rigid Box Corner Pasting Machine Suction Board Type Feeding Grey Board
Automatic Rigid Box Corner Pasting Machine Suction Board Type Feeding Grey Board
Automatic Rigid Box Corner Pasting Machine Suction Board Type Feeding Grey Board
Specifications
Brand Name :
WELLMARK
Model Number :
WM-SJT460
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1 set per 15 working days
Delivery Time :
5-8 workdays
Packaging Details :
Wooden case
Voltage :
220V/50Hz
Condition :
New
Warranty :
one year
After-sales service provided :
Engineers available to service machinery overseas
Automatic grade :
Automatic
Product name :
Automatic Rigid Box Making Machine Paper Box Corner Pasting Machine
Description

Suction Board Type Feeding Grey Board Automatic Rigid Box Corner Pasting Machine

Product features:

1, The machine adopts single arm press device and thermostatic temperature control system.

2, The machine can use various hot-melt adhesive tape, the width is usually 19mm. other width of tape have to special make it.

3, The length of adhesive tape can be adjusted between 10-60mm length by once for the different boxes.

4, The machine simple operation, fast working speed, high production efficiency, high cost performance.

5, This machine adopts suction board type feeding grey board, double table replacement paperboard.

Rigid Box Product Flew

Automatic Rigid Box Corner Pasting Machine Suction Board Type Feeding Grey Board Automatic Rigid Box Corner Pasting Machine Suction Board Type Feeding Grey Board

Other Product Recommend

Hot Tape / Hot Melt Tape / PET Tape

Technical Parameter

Model WM-SJT460
Grey Board Thickness 1-3mm
Max Length of Box 500mm
Min Length of Box 50mm
Max Width of Box 400mm
Min Width of Box 50mm
Max Height of Box 120mm
Min Height of Box 12mm
Speed 20-40pcs/min
Power 4.5kw
Air Pressure ≧0.6Mpa
Power Supply 380V/50Hz
Weight 2000kg
Machine Size L3000*W2400*H2600mm

Packing and Shipping

Packaging by wooden case and shipping by containers.
