Cell Phone Box Making Machine / Automatic Rigid Box Machine For Rigid Boxes

WM-DC450AB.pdf


Product Description

Full automatic rigid box making machine is a necessary equipment for making rigid box ,gift box ,packing box,cell phone box & etc.With advantages of small size,easy operation,fast speed.This machine can automatically start to edge fold,forming and wrap of box ,the advance PLC & variable frequency changer can control the speed freely,and equipped safety devices to ensure fast and safe production .Use the electric brushes to make the output rigid box more tightly and smoothly.


Product Character

Reasonable design, stable performance, equivalent to the international leading technology level. Adopt PLC programmable controller,HD Camera positioning system,Yamaha mechanical arm to take boxes positioning , touch human-machine interface. Realize the automatic feeding paper, automatic gluing cover paper, automatic positioning boxes, pressing air bubbles of boxes bottom, automatically take boxes from belt to wrapping and fold the ear side , folding into box and pressure air bubbles action series of one-time finish. The machine production efficiency is several times higher than that of the traditional craft production, also have fault diagnosis display and alarm function, operation safety guarantee. Suitable for making the high-quality goods class electronic products boxes, jewelry box, and other high-grade packing gift boxes with large quantity of orders,fast delivery terms.
Note: the maximum size of the box and minimal size depends on the paper at the same time the maximum and minimum size and surface quality of the paper. Speed will depending on the different boxes size with different paper materials.

Product Features
1. Automatically feed paper and boxes
2. 24-hours control for glue pre-heating (Optional configuration)
3. Spotter by 2pcs of 5 megapixel HD Camera tracing system and Yamaha mechanical arm to positioning (spotting accuracy ≤0.1mm)
4. Boxes molding department according to the boxes on the belt conveyor, operator collection box to molding department.
5. Boxes molding department, fold the ear, pressing the air bubble is forming a once-time.
6. The whole machine adopts PLC control, HD Camera positioning system, touch human-machine interface, the automatic production of rigid boxes forming process.
7. Computer control with error auto stop and display

Other Product Recommend

Box Corner Pasting Tape


Techical Parameters

Product Application

It is the ideal processing equipment rigid box, box. First, Inner box bottom paste with surface paper, then fix the product on the mold of the forming machine by hand, different size box with different mod, then automatic four side pasting, folding, and bubble pressing. Hardcover box can greatly improve the production efficiency.


Production Flew
