Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint
Specifications
Brand Name :
JINGBO
Model Number :
Universal Isolates Pipe Connection
Certification :
API
Place of Origin :
China
MOQ :
1 SET
Price :
100-1000 USD PER Meter
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
60,000 M Per Month
Delivery Time :
20 Days
Packaging Details :
Woven Bag + Iron Carton
Product Name :
Universal Self-Sealing Pipe Joint
Type :
Coupling
Material Standard :
ASTM and AISI
Condition :
New
Use :
Pipe Connection
Warranty :
6 months
Description

Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self-Sealing Pipe Joint

Universal Self-Sealing Pipe Joint Description of Rotary Drilling Hose

The self-sealing pipe joint automatically opens when mounting is finished and closes when dismantled, eliminating the possibility of polluting the environment by the out-flowing media, saving the operational cost, preventing the machines from abrasion by the sand and dust coming in the pipes and machines and reducing hazards for accidents. It allows easy mounting and dismantling, reduces labor intensity and saves operating time.

The materials used fully comply with ASTM and AISI standards of USA. The product and parts are all treated against corrosion. The pipe joint provides resistance to high pressure, reliable sealing, uniform standard and good exchangeability.

The universal self-sealing pipe joint provides automatic regulation depending on the connection direction, neat and aesthetic arrangement of pipelines and reduced fatigue resistance in the pipelines.

The self- sealing pipe joint is classified into the following two major families depending on the constructions:
Fast self-sealing steel ball pipe joint and Pin key plug-in self-sealing pipe joint

Rotary Drilling Hose Universal Self-Sealing Pipe Joint Datasheet

Nominal drift
diameter mm		 Total length
mm		 Max.operating
pressure MPa		 Experimental
pressure MPa		 Flow rate
I/min		 Connecting thread
6 62 52 78 16 M14×1.5
8 80 52 78 25 M16×1.5
10 90 52 78 40 M22×1.5
12 100 45 67.5 50 M27×1.5
15 106 45 67.5 63 M30×1.5
20 110 45 67.5 100 M36×2/1'' NPT
25 128 35 52.5 160 M42×2/1'' NPT
32 160 365 52.5 250 M52×2
40 190 21 31.5 400 M60×2
51 204 16 24 630 M68×2

Fast Connector Pipe Fitting Rotary Drilling Hose Universal Self Sealing Pipe Joint

FAQ

1. Who are we?
Topland is an integrated supplier established in 2008. We are a global group of oilfield supplies with excellent teams in more than 5 countries. such as UAE, Kuwait, Iran and Saudi Arabia. We cooperated with ADES, ECDE, EDC, SOCAR-AQS, PDL, SAKSON, ONGC etc.


2. How can we guarantee quality?
Always a double requirements and drawing checking before the production;
Always final Inspection before shipment;

3. What can you buy from us?
Drilling rig equipment and the related spares for the oil and natural gas industries. Like Rig Components, Drawworks Spare parts and Mud Pump Spare parts, Hydraulic Disc Brake,Solids Control Equipment, Drilling and Fishing Tools,Wellhead Control Equipment,Drilling Accessories, Cementing Equipment and Tools etc.

4. Why should you choose us?
4-1. Professional & Efficient, Customer Focus, Win-win Cooperation

4-2. Fast Quote, Competitive price & within shortest lead time

4-3. Complete Range of products, like spare parts which are interchangeable with most of the well-known OEM equipment.

4-2. Order tracking service

5. How is the packing?

All the packing will meet the strict export packing requirement, we surely know how important the beautiful and firm packaging to the goods.

6. What is your terms of payment?

A: Generally by T/T, 30% advance payment, the balance 70% payment should be paid before delivery. We support EXW, FOB, FCA, CFR, CIF, CIP, DAP, DDU and DDP INCO Terms.
