Specifications
Brand Name :
Keysight/Agilent/HP
MOQ :
1
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,Western Union,T/T,MoneyGram
Delivery Time :
3-5 days
New / Used :
Used
Outputs (Isolated CH1 + Tracking ± Rails) :
0 – 6 V @ 5 A, +25 V @ 1 A, –25 V @ 1 A (80 W total)
Resolution (Front Panel / SCPI) :
10 mV / 1 mA set & read-back
Programming Accuracy (25 °C) :
Voltage ±0.05 % + 20 mV (±0.1 % + 5 mV on –25 V); Current ±0.15 % + 4 mA (±0.2 % + 10 mA on –25 V)
Ripple & Noise (20 Hz–20 MHz) :
< 350 µV rms / 2 mV p-p (all rails)
Remote Control & Features :
GPIB + RS-232 (SCPI), remote-sense leads, over-voltage & over-current protection
Description

Agilent E3631A — 80 W Triple-Output 6 V / 5 A & ±25 V / 1 A DC Power Supply

The refurbished Agilent E3631A supplies three isolated outputs—6 V / 5 A for digital logic and complementary ±25 V / 1 A rails for analog circuitry—delivering a clean 80 W from one compact bench unit. Millivolt-level programming, < 350 µV rms noise and built-in remote-sense keep precision rails rock-steady, while SCPI control via GPIB or RS-232 drops straight into automated ATE scripts. Built-in OVP/OCP safeguards prototypes, and the ±25 V channels can track for symmetric supplies.

ISO-17025 calibration and updated firmware cut lead-time and cost, yet preserve Keysight reliability and full documentation for long-term serviceability.

80 W Triple Output Dc Power Supply 6 V / 5 A & ±25 V / 1 A Agilent E3631A

Contact TESTRO for a Fast Quote

Interested in an Agilent E3631A or a similar model?

  • Drop your WhatsApp number or e-mail on our website and we will:

    • Send a tailored quotation and any current promotions.

    • Provide extra photos, test data, and full configuration details.

    • Discuss shipping, duties, warranty, and any other specifics you need.

Looking for other models? Our inventory changes daily—ask for the latest list of spectrum analyzers and RF equipment.

80 W Triple Output Dc Power Supply 6 V / 5 A & ±25 V / 1 A Agilent E3631A

80 W Triple Output Dc Power Supply 6 V / 5 A & ±25 V / 1 A Agilent E3631A

TESTRO Advantages

  1. Laboratory-Verified Performance – Every unit ships with an ISO/IEC 17025 calibration certificate (TESTRO Certified) tied to its serial number.

  2. Full Internal Transparency – High-resolution teardown photos plus a live video test (gain-linearity, noise-floor, spurious response); recordings are stored for the product’s lifetime.

  3. Warranty & Technical Support – One-year warranty and weekday remote assistance from the in-house engineering team for both software and hardware issues.

  4. Secure, Rapid Shipping – Aviation-grade flight case with triple-layer anti-vibration foam and shock/tilt indicators; priority DHL delivery in 3–5 days to major destinations.

  5. Flexible Payment Options – Accepts T/T, wire transfer, credit card.

  6. On-Site Inspection Welcome – Customers may visit the Shenzhen warehouse and refurbishment line to view calibration benches, burn-in racks, and inventory.
