This 6-layer hybrid PCB combines Rogers RO4003C high-frequency material with S1000-2M substrate to deliver exceptional RF performance and reliability. Designed for microwave and millimeter-wave applications, this board features a robust 2.0mm thick construction with 1oz copper layers and precise 4/4 mil trace/space capabilities. The combination of materials provides outstanding signal integrity while maintaining cost-effective manufacturability.

Advanced Material Stackup for Optimal Performance
The board utilizes a carefully engineered 6-layer stackup:

Top and bottom layers: RO4003C laminate (0.508mm) for superior RF performance

Core layers: S1000-2M substrate (0.508mm) for enhanced thermal and mechanical properties

Prepreg layers: 1080 glass (0.127mm) for reliable interlayer bonding

The RO4003C laminate's unique thermal properties ensure outstanding reliability:

CTE closely matched to copper (X/Y: 11/14 ppm/°C) for exceptional dimensional stability

Low Z-axis CTE (46 ppm/°C) ensures plated through-hole integrity in thermal cycling

Ultra-high Tg (>280°C) maintains stability across all processing temperatures

Requires no special through-hole treatments unlike PTFE materials

Precision Manufacturing and Quality Assurance

Manufactured to exacting standards, this PCB features:

Tight dimensional tolerance (±0.15mm on 356mm x 373mm boards)

Reliable through-hole vias (0.35mm min, 20μm plating)

Durable HASL surface finish for excellent solderability

High-contrast white silkscreen on top layer

Distinctive blue solder mask on top surface

All boards undergo 100% electrical testing prior to shipment and meet IPC-Class-2 standards.

Technical Specifications:

Board Thickness: 2.0mm

Copper Weight: 1oz (35μm) all layers

Min Trace/Space: 4/4 mils

Min Hole Size: 0.35mm

Via Plating: 20μm

Surface Finish: HASL

Solder Mask: Blue (top only)

Silkscreen: White (top only)

Ideal for High-Frequency Applications:

Airborne and satellite communication systems
Radar and guidance systems
5G infrastructure and point-to-point radio
Microwave and millimeter-wave circuits
High-speed digital RF systems

Global Availability:
Available for worldwide shipment, these high-performance PCBs are perfect for engineers developing cutting-edge RF and microwave solutions.

The combination of Rogers RO4003C and S1000-2M materials provides an optimal balance of electrical performance, thermal management, and cost-effectiveness for demanding applications.
